2101-15

Frontier Electronics Corp. 667 E. COCHRAN STREET, SIMI VALLEY, CA 93065 TEL: (805) 522-9998 FAX: (805) 522-9989 E-mail: frontiersales@frontierusa.com Web: frontierusa.com Insert Molded Coil—2101 series A. Mechanical Drawing: B. Electrical Specification: Part No. 2101-01 2101-02 2101-03 2101-04 2101-05 2101-06 2101-07 2101-08 2101-09 2101-10 2101-11 2101-12 2101-13 2101-14 2101-15 2101-16 2101-17 2101-18 2101-19 2101-20 2101-21 2101-22 2101-23 Turns 1.5 2.5 3.5 4.5 5.5 6.5 7.5 8.5 9.5 10.5 11.5 12.5 13.5 14.5 15.5 16.5 17.5 18.5 19.5 20.5 21.5 22.5 23.5 L min. 0.045 0.073 0.106 0.139 0.180 0.221 0.263 0.311 0.355 0.410 0.452 0.495 0.547 0.589 0.651 0.683 0.735 0.788 0.819 0.887 0.945 0.996 1.050 L nom. 0.046 0.081 0.124 0.168 0.224 0.282 0.339 0.406 0.468 0.538 0.590 0.651 0.717 0.770 0.831 0.866 0.923 0.992 1.021 1.101 1.106 1.207 1.271 L max. 0.048 0.090 0.144 0.204 0.278 0.361 0.437 0.531 0.617 0.707 0.769 0.855 0.940 1.007 1.061 1.099 1.159 1.249 1.272 1.367 1.425 1.463 1.539 Q min @ L nom. 110 136 145 120 125 126 126 130 130 135 140 140 145 146 150 150 150 150 95 95 98 98 100 Color Brown Red Orange Yellow Green Blue Violet Gray White Black Brown Red Orange Yellow Green Blue Violet Gray White Black Brown Red Orange C. Features: 1. Plastic molded. 2. High reliability. 3. Low cost. D. Measurement: 1. 2. 3. 4. Q and L measured with leads connected directly. L min. measured with core halfway out of the top of the form. Inductance greater than 0.1uH read at recommended Q meter frequency. Inductance below 0.1uH calculated from readings taken at 50MHz. E. Test equipment: Q meter (HP 4342A) Mar. 01, 2002 Page 1 of 1 IMC 2101 series
