2303-03

Frontier Electronics Corp. 667 E. COCHRAN STREET, SIMI VALLEY, CA 93065 TEL: (805) 522-9998 FAX: (805) 522-9989 E-mail: frontiersales@frontierusa.com Web: frontierusa.com Insert Molded Coil—2303 series A. Mechanical Drawing: B. Electrical Specification: Part No. 2303-01 2303-02 2303-03 2303-04 2303-05 2303-06 2303-07 2303-08 2303-09 C. Features: 1. Plastic molded. 2. High reliability. 3. Low cost. L Min. (uH) 0.047 0.068 0.095 0.119 0.147 0.179 0.208 0.230 0.260 L Nom. (uH) 0.049 0.077 0.114 0.144 0.181 0.221 0.253 0.285 0.316 L Max. (uH) Q Min. @ L Nom. 0.051 110 0.088 125 0.137 140 0.174 140 0.223 145 0.272 150 0.308 150 0.352 154 0.384 155 Color Brown Red Orange Yellow Green Blue Violet Gray White D. Measurement: 1. 2. 3. 4. Q and L measured with leads connected directly. L min. measured without core. Inductance greater than 0.1uH read at recommended Q meter frequency. Inductance below 0.1uH calculated from readings taken at 50MHz. E. Test equipment: Q meter (HP 4342A) IMC 2303 series Mar. 01, 2002 Page 1 of 1
