2431-12

Frontier Electronics Corp. 667 E. COCHRAN STREET, SIMI VALLEY, CA 93065 TEL: (805) 522-9998 FAX: (805) 522-9989 E-mail: frontiersales@frontierusa.com Web: frontierusa.com Insert Molded Coil—2431 series A. Mechanical Drawing: B. Electrical Specification: Part No. 2431-09 2431-10 2431-11 2431-12 2431-13 2431-14 2431-15 2431-16 2431-17 2431-18 2431-19 2431-20 C. Features: 1. Plastic molded. 2. High reliability. 3. Low cost. L Min. (uH) 0.404 0.460 0.515 0.578 0.673 0.726 0.803 0.891 1.010 1.100 1.200 1.300 L Nom. (uH) 0.550 0.624 0.708 0.764 0.845 0.908 0.978 1.080 1.180 1.250 1.320 1.400 L Max. (uH) 0.693 0.788 0.900 0.950 1.020 1.090 1.150 1.270 1.340 1.400 1.440 1.500 Q Min. @ L Nom. 86 @ 40MHz 90 @ 40MHz 78 @ 40MHz 84 @ 40MHz 84 @ 40MHz 82 @ 40MHz 90 @ 40 MHz 74 @ 40 MHz 74 @ 40 MHz 92 @ 40 MHz 98 @ 40 MHz 92 @ 40 MHz Color White Black Brown Red Orange Yellow Green Blue Violet Gray White Black D. Measurement: 1. Q and L measured with ½” long of TCW#16 soldered along the coil leads and with one end flush with the bottom of the coil then bent ¼” down from stand off at an angle of 90°. 2. L min. measured with core halfway out of the top of the form. 3. Inductance greater than 0.1uH read at recommended Q meter frequency. 4. Inductance below 0.1uH calculated from readings taken at 50MHz. E. Test equipment: Q meter (HP 4342A) IMC 2431 series Mar. 01, 2002 Page 1 of 1
