FCN-07

DDR-2 DIMM SMT Vertical Mount Socket FCN-07 Series RoHS compliant ■ • • • FeaTuReS DDR-2: 240pin DIMM socket connector Co-planarity of 0.mm Fujitsu original unique structure for twin contact points structure, which is tolerant of dust and flux Specification -55°C to +85°C AC 0.5A AC/DC 25V DC20mv, 0mA 40mΩ maximum AC 0.25kV for  minute 250Mohm minimum Specification LCP, UL94 V-0 Copper Alloy Plating NiPdAu PL Double contact Roll surface Fujitsu’s FCN-07 DDR-2 DIMM socket is a vertical mount SMT socket. The unique contact structure provides for twin points of contact that insure that dust and flux are wiped clean when module is installed. In addition, the twin points guarantee constant contact between the module and contact even in a high vibration environment. Item Operating temperature range Current rating Voltage rating Contact resistance Contact resistance Dielectric withstanding voltage Insulation resistance Item Insulating material Contact Heating resisting tape Plastic tray quantity: 6 pieces/tray Container quantity: 16 x 5 = 80 pieces Fujitsu’s precision stamping and molding allow the connector to have a coplanarity specification of 0.mm. The connector has heat resistance tape added to the face of the connector for ease of vacuum pick-up. Due to the overall length of the of the connector, Fujitsu has added a “solder bars” in the middle of the connector to insure proper IR processing when soldering the connector to the PCB.  FCN-07 series DDR-2DIMM Socket ■ SPeCIFICaTIONS FCN-078J240-G/0 2 FCN-07 series DDR-2DIMM Socket ■ SPeCIFICaTIONS FCN-078J240-G/0 Fujitsu Components International Headquarter Offices Japan Fujitsu Component Limited Gotanda-Chuo Building -5, Higashigotanda 2-chome, Shinagawa-ku Tokyo 4 860, Japan Tel: (8-) 5449-700 Fax: (81-3) 5449-2626 Email: promothq@fcl.fujitsu.com Web: www.fcl.fujitsu.com North and South america Fujitsu Components America, Inc. 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (-408) 745-4900 Fax: (1-408) 745-4970 Email: components@us.fujitsu.com Web: http://us.fujitsu.com/components/ europe Fujitsu Components Europe B.V. Diamantlaan 25 22 WV Hoofddorp Netherlands Tel: (-2) 556090 Fax: (31-23) 5560950 Email: info@fceu.fujitsu.com Web: emea.fujitsu.com/components/ Asia Pacific Fujitsu Components Asia Ltd. 02E Pasir Panjang Road #01-01 Citilink Warehouse Complex Singapore 8529 Tel: (65) 675-8560 Fax: (65) 6273-3021 Email: fcal@fcal.fujitsu.com Web: http://www.fujitsu.com/sg/services/micro/components/ ©2009 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective owners. Fujitsu Components America or its affiliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our products Fujitsu Components America, Inc. or its affiliates reserve the right to change specifications/datasheets without prior notice. Rev. July 6, 2009.
