FCN-560

microSD/TF Card Connector FCN-560 Series microSD is currently the world’s smallest memory card storage system, specifically designed for use with ultra-small mobile phones and other devices. Like the miniSD, the microSD/TransFlash is ideal for use in storing media-rich files such as music, videos, and photographs in compatible mobile phones. Fujitsu’s microSD connector offers the lowest profile height (1.65mm) currently available in the market. Featuring Fujitsu’s precise and insert molding technology, the FCN-560 series micro SD connector measures 5mm (D) x 4mm (W) x .6mm (H) and has a life cycle of ten thousand insertions/withdrawals. Fujitsu’s connector uses a proprietary push-push structure that provides positive tactile feedback during card insertion and withdrawal. A card drop protection mechanism prevents the card from falling out during pre-insertion and forced card extraction after it’s locked in. When ejected, the card travels 3.5mm from its locked position. roHS compliant ■ • • • • • • FeaTureS Reduction in seize and weight (5 (D) x 4 (W) x .65 (H)mm) with unique push-push structure Half-lock to prevent forced card extraction, good operability with sense of click for insertion Smooth card inserion/withdrawl with unique drop-protection mechanism With card detections switch Card ejection distance 3.5mm FCN-568Z008-G/0M Item Operating temperature range Current rating Voltage rating Contact resistance Dielectric withstanding voltage Insertion/Withdrawl life Specification -20°C to +70°C AC 0.5A AC/DC 5V 100mΩ maximum AC 500V for  minute 0,000 cycles Item Insulating material Contact Pin / Spring Metal Cover Specification LCP, UL94 V-0 Copper Alloy Plating NiPdAu SWPA Stainless steel Tape and reel: , 500 pcs/reel  microSD/TF Card Connector ■ SPeCIFICaTIONS 2 microSD/TF Card Connector ■ SPeCIFICaTIONS Fujitsu Components International Headquarter Offices Japan Fujitsu Component Limited Gotanda-Chuo Building 3-5, Higashigotanda 2-chome, Shinagawa-ku Tokyo 4 8630, Japan Tel: (8-3) 5449-700 Fax: (8-3) 5449-2626 Email: promothq@fcl.fujitsu.com Web: www.fcl.fujitsu.com North and South america Fujitsu Components America, Inc. 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (-408) 745-4900 Fax: (-408) 745-4970 Email: components@us.fujitsu.com Web: http://us.fujitsu.com/components/ europe Fujitsu Components Europe B.V. Diamantlaan 25 232 WV Hoofddorp Netherlands Tel: (3-23) 556090 Fax: (3-23) 5560950 Email: info@fceu.fujitsu.com Web: emea.fujitsu.com/components/ Asia Pacific Fujitsu Components Asia Ltd. 02E Pasir Panjang Road #0-0 Citilink Warehouse Complex Singapore 8529 Tel: (65) 6375-8560 Fax: (65) 6273-302 Email: fcal@fcal.fujitsu.com Web: http://www.fujitsu.com/sg/services/micro/components/ ©2007 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective owners. Fujitsu Components America or its affiliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our products Fujitsu Components America, Inc. or its affiliates reserve the right to change specifications/datasheets without prior notice. Rev. October , 2007. 3
