FTR-C1

FTR-K1 SERIES POWER RELAY 2 POLES-2A High Insulation/wide Gap FTR-C1 Series n FEATURES l l 2 Poles, 2 form C Contact gap: more than 0.6mm l High surge voltage: 2500V between open contacts 5000V between coil & contact Complies with Telcordia (former Bellcore) 2nd level surge l Dielectric strength: 1500VAC between open contacts 3000VAC between coil and contact l Dimensions of large contact gap relay Height: 9.3mm maximum (THT) 9.65mm maximum (SMT) Length: 15mm maximum Width: 7.5mm maximum l Conforms to IEC60950/ EN60950/UL1950/CSA C 22.2 No. 950 working voltage 250V (supplementary) l High insulation: Clearance: min 2.0mm (coil and contacts) Creepage: min 2.5mm (coil and contacts) l High reliability-Bifurcated contacts l Low power consumption 280mW (latching type 140mW) l RoHS compliant n PARTNUMBER INFORMATION FTR-C1 C A 012 G - B05 [Example] (a) (b) (c) (d) (e) (f) (a) (b) (c) (d) (e) (f) Relay type Contact Configuration Coil Type / Enclosure Coil rated Voltage Contact Material Tape / reel ordering FTR-C: FTR-C Series C G S A B 012 G Nil B05 : Through hole type : Surface mount type : Surface mount type-reduced mounting area : Standard type : Single coil latching type : 3.....24 VDC Coil table at page 3 : Gold plated silver palladium : standard packaging (tube) : tape / reel package, only available for SMT type Actual marking does not carry the type name : "FTR" E.g.: Ordering code: FTR-C1CA012G Actual marking: C1CA012G  FTR-K1 SERIES FTR-C1 SERIES n SPECIFICATION Item Contact Data Configuration Construction Material Resistance (Initial) Contact rating resistive Max. Switching Voltage Max. Switching Power Max. Carry Current Min. Switching Load * Life Coil Data Mechanical Electrical Rated Power Operate Power Operating temp range Timing Data Insulation Operate Release Resistance (Initial) Dielectric strength Strength Surge strength Clearance Clearance Clearance Creepage Creepage Other Vibration Resistance Shock Weight Open contacts Contacts to coil Coil to contacts open contacts adjecent contacts coil and contacts open contacts coil and contacts Misoperation>1us Endurance Misoperation>1us Endurance Non-latching FTR-C1 ( ) A C Bifurcated Gold plated silver palladium ≤ 100mOhm @1A, 6VDC 1A, 30VDC / 0.3A, 125VAC / 0.3A, 110VDC 250VAC / 220VDC 62.5VA / 30W 2A 10mA, 10mVDC 2x 10^6 100x 10^3 at 0.3A, 125VAC / 1A, 30VDC 280 to 300mW 158 to 162mW -40 to +85C (no frost) ≤ 6ms (at nominal voltage, no bounce) ≤ 6ms (at nominal voltage, no bounce) ≥ 1000MOhm @500VDC 1500VAC (50/60Hz) 1min 3000VAC (50/60Hz) 1min 5000V, 1.2 x 10µs standard wave / 6000V, 1.2 x 50µs 0.6mm 1.54mm 2.0mm 1.54mm 2.0mm 10 to 55Hz double amplitude 3.3mm 10 to 55Hz double amplitude 5mm Min. 500m/s^2 Min. 1000m/s^2 Approx. 2 g 140 to 180mW 158 to 162mW Latching FTR-C ( ) B * Minimum switching loads mentioned above are reference values. Please perform the confirmation test with actual load before production since reference values may vary according to switching frequencies, environmental conditions and expected reliability levels.  FTR-K1 SERIES FTR-C1 SERIES n COIL RATING Standard type Coil Code 00 4.5 005 0 04 Rated Coil Coil Resistance Voltage +/- 10% (Ohm) (VDC)  6 9  18 . 72.3 89.3 54 1920 Must Operate Must ReleaseMax. Coil Voltage Voltage Voltage (V) (V) *¹ (V) *¹ .5 3.38 3.75 9 18 0. 0.45 0.5 . .4 4.5 6.75 7.5 18 36 00 0 Nominal Coil Power (mW) Latching type Coil Code 00 4.5 005 0 04 Rated Coil Coil Resistance Voltage +/- 10% (Ohm) (VDC)  4.5 5  4 64.0 45 179 1029 00 Must Operate Must ReleaseMax. Coil Voltage Voltage Voltage (V) (V) *¹ (V) *¹ +.5 +3.38 +3.75 +9 +18 .5 3.38 3.75 9 18 4.5 6.75 7.5 18 36 180 40 Nominal Coil Power (mW) Note: All values in the table are measured at 20°C. No contact current at 20°C *1: Specified values are subject to pulse wave voltage n SAFETY STANDARDS Type UL Compliance UL 508 E63615 CSA BSI C22.2 No. 14 LR 4004 IEC 60950-1 Contact rating Flammability: UL 94-V0 (plastics) 0.3A, 125 VAC (resistive) 1 A, 30VDC 0.3A, 110VDC  FTR-K1 SERIES FTR-C1 SERIES n DIMENSIONS AND SCHEMATICS Through hole type Unit: mm n TERMINAL DESIGNATIONS Standard type (Bottom view de-energized position) n RECOMMENDED MOUNTING PAD Single Coil Latching type (Bottom view reset position) S shows the polarity of set positin R shows the polarity of reset position Unit: mm 4 FTR-K1 SERIES FTR-C1 SERIES n DIMENSIONS AND SCHEMATICS Surface mount type n TERMINAL DESIGNATIONS Standard type (Bottom view reset position) n RECOMMENDED MOUNTING PAD Single Coil Latching type (Bottom view reset position) S shows the polarity of set positin R shows the polarity of reset position Unit: mm 5 FTR-C1 SERIES FTR-K1 SERIES n DIMENSIONS AND SCHEMATICS Space saving type PC board mounting pad layout Top view Schematics Top view Unit: mm 6 FTR-K1 SERIES FTR-C1 SERIES n RECOMMENDED SOLDERING CONDITIONS SMT (TEMPERATURE PROFILE, please see page 9) Note: 1.Temperature profiles show the temperature of PC board surface. 2. Please perform soldering test with your actual PC board before mass production, since the temperatures of PC board surfaces vary according to the size of PC board, status of parts mounting and heating method. n PACKAGING Packaging method (only tape packaging is available) 1. Taping standards: JIS C 0806 and RC-10092B (EIAJ) 2. Reel type: TB2416 or TB2416 3. Reel type: RD24D 4. Quantity of 1 reel: 500 pieces Tape Dimensions: Reel Dimensions: Unit: mm 7 FTR-K1 SERIES FTR-C1 SERIES RoHS Compliance and Lead Free Information 1. General Information All signal and power relays produced by Fujitsu Components are compliant with RoHS directive 2002/95EC including amendments. l Cadmium as used in electrical contacts is exempted from the RoHS directives on October 21st, 2005. (Amendment to Directive 2002/95/EC) l All of our signal and power relays are lead-free. Please refer to Lead-Free Status Info for older date codes at: http://www.fujitsu.com/us/downloads/MICRO/fcai/relays/lead-free-letter.pdf l Lead free solder plating on relay terminals is Sn-3.0Ag-0.5Cu, unless otherwise specified. This material has been verified to be compatible with PbSn assembly process. l “LF” is marked on each outer and inner carton. (No marking on individual relays). l 2. Recommended Lead Free Solder Profile l Recommended solder Sn-3.0Ag-0.5Cu. Flow Solder condition: Pre-heating: Soldering: maximum 120˚C dip within 5 sec. at 260˚C solder bath Solder by Soldering Iron: Soldering Iron Temperature: maximum 360˚C Duration: maximum 3 sec. We highly recommend that you confirm your actual solder conditions 3. Moisture Sensitivity l Moisture Sensitivity Level standard is not applicable to electromechanical relays, unless otherwise indicated. 4. Tin Whiskers Dipped SnAgCu solder is known as presenting a low risk to tin whisker development. No considerable length whisker was found by our in house test. l 8 FTR-K1 SERIES FTR-C1 SERIES Fujitsu Components International Headquarter Offices Japan Fujitsu Component Limited Gotanda-Chuo Building 3-5, Higashigotanda 2-chome, Shinagawa-ku Tokyo 141, Japan Tel: (81-3) 5449-7010 Fax: (81-3) 5449-2626 Email: promothq@ft.ed.fujitsu.com Web: www.fcl.fujitsu.com North and South America Fujitsu Components America, Inc. 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (1-408) 745-4900 Fax: (1-408) 745-4970 Email: components@us.fujitsu.com Web: http://www.fujitsu.com/us/services/edevices/components/ Europe Fujitsu Components Europe B.V. Diamantlaan 25 2132 WV Hoofddorp Netherlands Tel: (31-23) 5560910 Fax: (31-23) 5560950 Email: info@fceu.fujitsu.com Web: emea.fujitsu.com/components/ Asia Pacific Fujitsu Components Asia Ltd. 102E Pasir Panjang Road #01-01 Citilink Warehouse Complex Singapore 118529 Tel: (65) 6375-8560 Fax: (65) 6273-3021 Email: fcal@fcal.fujitsu.com Web: http://www.fujitsu.com/sg/services/micro/components/ ©2009 Fujitsu Components Europe B.V. All rights reserved. All trademarks or registered trademarks are the property of their respective owners. The contents, data and information in this datasheet are provided by Fujitsu Component Ltd. as a service only to its user and only for general information purposes. The use of the contents, data and information provided in this datasheet is at the users’ own risk. Fujitsu has assembled this datasheet with care and will endeavor to keep the contents, data and information correct, accurate, comprehensive, complete and up to date. Fujitsu Components Europe B.V. and affiliated companies do however not accept any responsibility or liability on their behalf, nor on behalf of its employees, for any loss or damage, direct, indirect or consequential, with respect to this datasheet, its contents, data, and information and related graphics and the correctness, reliability, accuracy, comprehensiveness, usefulness, availability and completeness thereof. Nor do Fujitsu Components Europe B.V. and affiliated companies accept on their behalf, nor on behalf of its employees, any responsibility or liability for any representation or warrant of any kind, express or implied, including warranties of any kind for merchantability or fitness for particular use, with respect to these datasheets, its contents, data, information and related graphics and the correctness, reliability, accuracy, comprehensiveness, usefulness, availability and completeness thereof. Rev. June 4, 2009 9
