VG-12-K-UL

POWER RELAY 1 POLE—3A to 5 A (CADMIUM FREE CONTACTS TYPE) VG SERIES s FEATURES q q q q q q q UL, CSA recognized, TV-5 rated 1 form A (SPST-NO) or 1 form C (SPDT) contact Reliable, low power consumption miniature power relay —Surge strength 7,000 V Slim type—meets high density mounting requirement Easy circuit design with completely separated terminal arrangement (coil and contact terminals) Plastic sealed type backfilled with nitrogen available Environmentally friendly cadmium free contact type is available s ORDERING INFORMATION [Example] (a) (b) (c) VG – 12 (a) (*) (b) Series Name Nominal Voltage Contact Rating (d) (e) (f) Contact Arrangement Coil Type Contact Material (Rating) DI SC ON TIN UE D H (c) M (d) S (e) E – K – UL (f ) (g) (h) VG: VG Series Refer to the COIL DATA CHART Nil : 3 A H : 5A T : 5 A (only TV-5) Nil : 1 form C (SPDT) M : 1 form A (SPST-NO) Nil : Standard type S : High sensitivity type (only 3 A type available) Nil : Gold overlay silver-nickel (3 A, 5 A) Nil : Silver alloy (only TV-5) E : Silver-nickel (3 A, 5 A) Nil : Flux free type C : Plastic sealed type (with tape) K : Plastic sealed type UL : UL, CSA approved type (g) Enclosure (h) Standard Note: Actual marking omits the hyphen (-) of (*) 1 VG SERIES s SAFETY STANDARD AND FILE NUMBERS UL508, 873 (File No. E56140) C22.2 No. 1, No. 14 (File No. LR35579) Please note that UL/CSA ratings may differ from the standard ratings. Type TV-Rating VG-TM Nominal voltage 5 to 48 VDC Contact rating TV-5 120 VAC 1/8 HP 120 VAC/240 VAC 5 A 24 VDC/240 VAC resistive (*) Pilot duty C 150 1/8 HP 120 VAC/240 VAC 5 A 24 VDC/120 VAC resistive Pilot duty C 150 1/10 HP 120 VAC/240 VAC 3 A 30 VDC/120 VAC resistive Pilot duty D 150 General VG-H 5 to 48 VDC * Only UL approval DI SC ON TIN UE D VG 5 to 48 VDC 2 VG SERIES s SPECIFICATIONS Standard Type Item TV-5 Type VG-( ) TM Contact Arrangement Material Style Resistance (initial) (at 1 A 6 VDC) Rating (resistive) Maximum Carrying Current Maximum Switching Power 1 form A (SPST-NO) Silver alloy Single Maximum 200 mΩ Maximum 70 mΩ (VG-H,VG), Max. 100 mΩ (VG-HE, E) 5 A 120 VAC 5 A 24 VDC 5A 3 A 120 VAC 3 A 30 VDC 5 A Type VG-( ) H VG-( ) HE 3 A Type VG VG-E High Sensitive Type 3 A Type VG-S VG-SE 1 form A (SPST-NO) or 1 form C (SPDT) Gold overlay silver alloy (VG-H, VG), silver alloy (VG-HE,E) Coil Time Value Insulation Life Other DI SC ON TIN UE D 1,000 VA, 150 W 500 VA, 90 W Maximum Switching Voltage Maximum Switching Current Minimum Switching Load*1 Nominal Power (at 20°C) 250 VAC, 150 VDC 5A 3A 10 mA 5 VDC (VG-H,VG), 100 mA 5 VDC (VG-TM,VG-HE, E) 0.36 to 0.4 W Operate Power (at 20°C) Operating Temperature 0.18 to 0.2 W –40°C to +70°C (no frost) Operate (at nominal voltage) Maximum 10 ms Maximum 5 ms Release (at nominal voltage) Resistance (at 500 VDC) Minimum 1,000 MΩ Dielectric Strength between open contacts 900 VAC 1 minute 750 VAC 1 minute between coil and contacts 4,000 VAC 1 minute Surge Strength 7,000 V (at 1.2 × 50 µs) Mechanical Electrical 1 × 107 operations minimum 1 × 105 operations minimum (at contact rating) 10 to 55 Hz (double amplitude of 1.5 mm) 100 m/s2 (11 ±1 ms) 1,000 m/s2 (6 ±1 ms) Approximately 12 g Vibration Resistance Shock Resistance Weight Misoperation Endurance Misoperation Endurance 10 to 55 Hz (double amplitude of 1.5 mm) 0.21 to 0.26 W 0.102 to 0.13 W –40°C to +85°C (no frost) *1 Minimum switching loads mentioned above are reference values. Please perform the confirmation test with the actual load before production since reference values may vary according to switching frequencies, environmental conditions and expected reliability levels. 3 VG SERIES s COIL DATA CHART MODEL TV 5 A Type VG- 5TM Standard Type VG- 6TM VG- 9TM VG-12TM VG-18TM VG-24TM VG-48TM Standard Type 5 A Type VG- 5H (M) (E) VG- 6H (M) (E) VG- 9H (M) (E) VG-12H (M) (E) VG-18H (M) (E) VG-24H (M) (E) VG-48H (M) (E) 3 A Type VG- 5 (M) (E) VG- 6 (M) (E) VG- 9 (M) (E) VG-12 (M) (E) VG-18 (M) (E) VG-24 (M) (E) VG-48 (M) (E) 5 VDC 6 VDC 9 VDC 12 VDC 18 VDC 24 VDC 48 VDC Nominal voltage Coil resistance (±10%) 69 Ω 100 Ω 225 Ω 400 Ω 870 Ω 1,450 Ω 6,000 Ω 120 Ω 150 Ω 325 Ω 575 Ω Must operate voltage 35 VDC 4.2 VDC 6.3 VDC 8.4 VDC 12.6 VDC 16.8 VDC 33.6 VDC Must release voltage 0.25 VDC 0.3 VDC 0.45 VDC 0.6 VDC 0.9 VDC 1.2 VDC 2.4 VDC Nominal power 360 mW 360 mW 360 mW 360 mW 380 mW 400 mW 390 mW 210 mW 240 mW 250 mW 250 mW 240 mW 260 mW Note: All values in the table are measured at 20°C. s CHARACTERISTIC DATA DI SC ON TIN UE D VG- 5 (M) S (E) VG- 6 (M) S (E) VG- 9 (M) S (E) VG-12 (M) S (E) VG-18 (M) S (E) VG-24 (M) S (E) 5 VDC 6 VDC 9 VDC 3.5 VDC 4.2 VDC 6.3 VDC 8.4 VDC 0.25 VDC 0.3 VDC 0.45 VDC 12 VDC 18 VDC 24 VDC 0.6 VDC 1,400 Ω 2,230 Ω 12.6 VDC 16.8 VDC 0.9 VDC 1.2 VDC High Sensitive Type 4 VG SERIES s REFERENCE DATA DI SC ON TIN UE D 5 VG SERIES s DIMENSIONS q Dimensions VG-M type q Schematics (BOTTOM VIEW) q PC board mounting hole layout (BOTTOM VIEW) VG type VG-M-K type (Plastic sealed type) DI SC ON TIN UE D VG-K type (Plastic sealed type) Unit: mm 6 VG SERIES q Dimensions q Schematics (BOTTOM VIEW) q PC board mounting hole layout (BOTTOM VIEW) VG-M-C type (Plastic sealed type with tape) VG-C type (Plastic sealed type with tape) DI SC ON TIN UE D Japan Fujitsu Component Limited Gotanda-Chuo Building 3-5, Higashigotanda 2-chome, Shinagawa-ku Tokyo 141, Japan Tel: (81-3) 5449-7010 Fax: (81-3) 5449-2626 Email: promothq@ft.ed.fujitsu.com Web: www.fcl.fujitsu.com North and South America Fujitsu Components America, Inc. 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (1-408) 745-4900 Fax: (1-408) 745-4970 Email: marcom@fcai.fujitsu.com Web: www.fcai.fujitsu.com Asia Pacific Fujitsu Components Asia Ltd. 102E Pasir Panjang Road #04-01 Citilink Warehouse Complex Singapore 118529 Tel: (65) 375-8560 Fax: (65) 273-3021 Email: fcal@fcal.fujitsu.com www.fcal.fujitsu.com Unit: mm Fujitsu Components International Headquarter Offices Europe Fujitsu Components Europe B.V. Diamantlaan 25 2132 WV Hoofddorp Netherlands Tel: (31-23) 5560910 Fax: (31-23) 5560950 Email: info.marketing@fceu.fujitsu.com Web: www.fceu.fujitsu.com © 2001 Fujitsu Components America, Inc. All company and product names are trademarks or registered trademarks of their respective owners. Rev. 09/2001 7
