VRB-6

POWER RELAY 1 POLE—15 A (HEAVY POWER CONTROL) VR SERIES s FEATURES q q q q q q UL, CSA, VDE recognized TV-5 rated 1 Form A (SPST-NO) contact Heavy duty 15 A miniature power relay with tab-terminals (#187) UL class B (130°C) insulation High isolation and high surge strength —Insulation distance: 8 mm —Dielectric strength: 5,000 VAC (between coil and contacts) —Surge strength: 10,000 V VRB type—good for high density mounting NO B – (b) (*) 12 (c) s ORDERING INFORMATION [Example] (a) VR (a) DE TF SI Series Name VR: VR Series (b) Terminal Nil: Top ......... Tab-terminal (contacts) Bottom .... PCB terminal (coil) B: Top ......... Tab-terminal (contacts) Bottom .... PCB terminal (coil and movable contact) Refer to the COIL DATA CHART (c) Nominal Voltage NE GN W S Contact rating TV-5 1HP 15 A 120 VAC 250 VAC 277 VAC/30 VDC resistive Pilot duty B 150 OR Actual marking omits the hyphen (–) of (*) s SAFETY STANDARD AND FILE NUMBERS UL508 (File No. E56140, E108658) C22.2, No. 1, No. 14 (File No. LR35579) VDE0435, 0631, 0700 Type VR VRB Nominal voltage 3 to 60 VDC 1 VR SERIES s SPECIFICATIONS Item Contact Arrangement Material Style Resistance (initial) (at 1 A 6 VDC) Rating (resistive) Maximum Carrying Current Maximum Switching Power Maximum Switching Voltage Maximum Switching Current Minimum Switching Load *1 Coil Nominal Power (at 20°C) Operate Power (at 20°C) Operating Temperature 1 form A (SPST-NO) Silver-cadmium oxide Single Maximum 100 mΩ 15 A 30 VDC/277 VAC 15 A 4,155 VA, 450 W 277 VAC, 30 VDC 15 A 100 mA 5 VDC VR, VRB NO Time Value Operate (at nominal voltage) Release (at nominal voltage) Insulation Resistance (at 500 VDC) between open contacts Dielectric Strength between coil and contacts Surge Strength Life Mechanical Electrical Other Vibration Resistance Shock Resistance Weight Misoperation Endurance Misoperation Endurance DE TF SI 0.8 W 0.36 W –40°C to +85°C (no frost) (refer to the CHARACTERISTIC DATA) Maximum 15 ms Maximum 10 ms Minimum 1,000 MΩ 1,000 VAC 1 minute 5,000 VAC 1 minute 10,000 V (at 1.2 × 50 µs) 5 × 106 operations minimum 1 × 105 operations minimum (contact rating) 10 to 55 Hz (double amplitude of 1.65 mm) 10 to 55 Hz (double amplitude of 2.0 mm) 200 m/s2 (11 ± 1 ms) 1,000 m/s2 (6 ± 1 ms) Approximately 24 g NE GN W S OR *1 Minimum switching loads mentioned above are reference values. Please perform the confirmation test with the actual load before production since reference values may vary according to switching frequencies, environmental conditions and expected reliability levels. 2 VR SERIES s COIL DATA CHART MODEL VR (B)- 3 VR (B)- 5 VR (B)- 6 VR (B)- 9 VR (B)-12 VR (B)-14 VR (B)-18 VR (B)-24 VR (B)-48 VR (B)-60 Nominal voltage 3 VDC 5 VDC 6 VDC 9 VDC 12 VDC 14 VDC Coil resistance (± 10%) 11.2 Ω 31 Ω 45 Ω 101 Ω 180 Ω 245 Ω 405 Ω 720 Ω 2,880 Ω 4,500 Ω Must operate voltage 2.0 VDC 3.3 VDC 4.0 VDC 6.0 VDC 8.1 VDC 9.4 VDC 12.1 VDC 16.2 VDC 32.4 VDC 40.5 VDC Must release voltage 0.3 VDC 0.5 VDC 0.6 VDC 0.9 VDC 1.2 VDC 1.4 VDC 1.8 VDC 2.4 VDC 4.8 VDC 6.0 VDC Nominal power 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W 0.8 W Note: All values in the table are measured at 20°C NO 18 VDC 24 VDC 48 VDC 60 VDC s CHARACTERISTIC DATA DE TF SI NE GN W S OR 3 VR SERIES s REFERENCE DATA NO DE TF SI NE GN W S OR 4 VR SERIES s DIMENSIONS q Dimensions VR type q Schematics q PC board mounting hole layout NO VRB type DE TF SI (BOTTOM VIEW) NE GN W S (BOTTOM VIEW) Unit: mm Europe Fujitsu Components Europe B.V. Diamantlaan 25 2132 WV Hoofddorp Netherlands Tel: (31-23) 5560910 Fax: (31-23) 5560950 Email: info@fceu.fujitsu.com Web: www.fceu.fujitsu.com Asia Pacific Fujitsu Components Asia Ltd. 102E Pasir Panjang Road #04-01 Citilink Warehouse Complex Singapore 118529 Tel: (65) 375-8560 Fax: (65) 273-3021 Email: fcal@fcal.fujitsu.com www.fcal.fujitsu.com OR Fujitsu Components International Headquarter Offices Japan Fujitsu Component Limited Gotanda-Chuo Building 3-5, Higashigotanda 2-chome, Shinagawa-ku Tokyo 141, Japan Tel: (81-3) 5449-7010 Fax: (81-3) 5449-2626 Email: promothq@ft.ed.fujitsu.com Web: www.fcl.fujitsu.com North and South America Fujitsu Components America, Inc. 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (1-408) 745-4900 Fax: (1-408) 745-4970 Email: marcom@fcai.fujitsu.com Web: www.fcai.fujitsu.com © 2002 Fujitsu Components America, Inc. All company and product names are trademarks or registered trademarks of their respective owners. Rev. 03/2002 5
