AA-100

AA Series Amplifiers Amplifiers for Emergency Voice Evacuation Systems Description • The Gamewell-FCI AA Series audio amplifiers provide the latest audio technology and bulk amplification for the Gamewell-FCI E3 Series™ Classic Emergency Voice Evacuation System. Two (2) models are available. The Model AA-100 provides 100 watts @ 70.7 VRMS (power-limited), while the Model AA-120 provides 120 watts @ 25 VRMS (power-limited). Both models use high-efficiency, power-switching, regulation technology to reduce the generation of heat, and minimize the size for ease of installation. An integral automatic back-up tone generator allows for slow whoop or high/low signal tones. The amplifiers include power supply, battery transfer control, amplifier supervision and back-up amplifier transfer control. AA Amplifier Features • AA-100 provides dual outputs of up to 100 watts @ 70.7 VRMS (max. 100 watts of combined output). • AA-120 provides up to 120 watts @ 25 VRMS. • Low power standby mode for low battery drain. • Includes “Grouped” or “One-to-One” backup amplifier switching bus. • Battery input and brown-out transfer control. • High efficiency power-switching regulation technology. • Plug-in terminal strips and cable connectors for ease of installation. Indicators and Controls Normal Level Incorrect Level Amplifier Trouble Speaker Trouble Brown-out/AC Failure Battery Supervision Green LED Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED Specifications Rated Output: Output Voltage: Total harmonic distortion@ 1 kHz: Frequency response (+3, -1dB): Supply Voltage: Power consumption @ 120 VAC: 24 VDC (battery) consumption: Dimensions: Weight: 100 watts RMS (AA-100) 120 watts RMS (AA-120) 70.7 VRMS (AA-100) 25 VRMS (AA-120) 4.0% 170-7, 500 Hz 120 V, 60 Hz Standby:.306 A Alarm: 1.85 A Standby:.051 A 7.0” H x 19.0” W x 4.5” D (17.8 H x 48.3 W x 11.4 D cm) 16.0 lbs. (35.3 kg.) • 10-position level adjust and indicator LEDs. • Integral chassis for cabinet mount. • Includes automatic back-up tone generator (slow whoop or high/low). Ordering Information Model AA-100 AA-120 Description Amplifier, 100W Amplifier, 120W An ISO 900 1-20 00 Com pa ny SIGNALING FM APP ROVE D E3 Series™ is a trademark of Honeywell International Inc. S1949 3 022355 6911-0694:260 GAMEWELL-FCI Specifications are for information only, are not intended for installation purposes, and are subject to change without notice. No responsibility is assumed by Gamewell-FCI for their use. ©2007 by Honeywell International Inc. All rights reserved. www.gamewell-fci.com 9020-0595 Rev. D2 page 1 of 1 12 Clintonville Road, Northford, CT 06472-1610 USA • Tel: (203) 484-7161 • Fax: (203) 484-7118
