MS-2-D

MS SERIES www.gamewell.fci.com Model MS-2, MS-2H The MS-2 manual fire alarm stations are dual action devices. These stations require that the outer door be lifted to expose the actuation door which is then pulled forward to operate the alarm toggle switch. The actuation door is now locked in the readily observable “alarm” position. To reset the station, a key (common to FCI control panels) must be inserted and turned ¼ turn clockwise, opening the station. Closing the station resets the switch automatically. An optional breakglass rod is available for positive indication of station operation. Model MS-2L (Institutional) Operation of the Model MS-2L institutional station requires that a special key be used to release the actuation door before it can be operated. Model MS-2-D (Multiple Contact) The MS-2-D features a DPST switch for multiple signaling via wire lead connections. Model MS-6 (Single Action) The MS-6 station is a single action device, requiring only the pulling of the action door to release the compressed button switch. It is available either with terminals (MS-6T) or wire leads (MS-6). The station resets in the same manner as the MS-2. The reset key is common to FCI control panels. FEATURES NON-CODED, MANUAL FIRE ALARM STATIONS • Single and Dual Action Versions • Tumbler Lock for Test and Reset Keyed Alike with FCI Control Panels • Rugged Metal Construction • Positive Indication of Operation over 180° Viewing Angle • Surface or Semi-flush Mounting • Shock and Vibration Resistant • Institutional Version (MS-2L) • Optional “FIRE SUPPRESSION SYSTEM RELEASE” Markings (MS-2H) • Optional DPST Switch (MS-2-D) MS-2 MS-2H MS-6 An ISO 9001 Company Specifications are provided for information only, are not intended to be used for installation purposes and are believed to be accurate. However, no responsibility is assumed by Gamewell-FCI for their use. Specifications subject to change without notice. © 2006 All Rights Reserved. 9020-0358 Rev. I Page 1of 2 MS SERIES AGENCY APPROVALS UL (Std 38) FM (MS-2) (MS-6, MS-6T) C.S.F.M. NYC-BS&A (MS-2) NYC-MEA (MS-6) File S2465 OJ3A9.AY/12880 1D4A7.AY 7150-0694:107 960-81-SA 103-93-E SPECIFICATIONS Material (MS-2, MS-6) Doors (MS-2, MS-6) Switch Type MS-2 MS-6 Contact Material Contact Ratings MS-2 MS-6 Dimensions (overall) MS-2, MS-6 Extruded 6063/T5 aluminium Clear anodize Enclosed toggle Enclosed push button Silver plated bronze or copper 6 amp. max. @ 30 VDC (resistive) 0.5 amp. max. @ 30 VDC (resistive) 5” H x 3.4” W x 2.8” D (12.7 cm x 8.64 cm x 7.11 cm) ORDERING INFORMATION Part No. 1100-0615 1100-0634 1100-0621 1100-0617 1100-0632 1100-0633 2520-0023 1120-0206 Model MS-2 MS-2H MS-2L MS-2-D MS-6 MS-6T BB-2 Description Dual action fire alarm station Dual action station with “FIRE SUPPRESSION SYSTEM RELEASE” markings Institutional fire alarm station Dual action station with DPST switch Single action station, wire leads Single action station, terminals Surface back box for MS-2, MS-6 stations Package of two replacement breakglass rods for MS-2 station © 2006 All Rights Reserved Specifications are provided for information only, are not intended to be used for installation purposes and are believed to be accurate. However, no responsibility is assumed by Gamewell-FCI, for their use. Specifications subject to change without notice. GAMEWELL-FCI 12 Clintonville Road, Northford, CT 06472 - Tel: (203) 484-7161 - Fax: (203) 484-7118 www.gamewell.fci.com 9020-0358 Rev. I Page 2 of 2
