Gamewell Voice Fire Phone Accessories Description Fire phone accessories give the Gamewell Voice system two-way communication capability. Fire phone jacks are mounted on a single-gang plate. Fixed telephone and warden stations are available in surface/semi-flush-mount cabinet with a thumbturn latch. Listings Listings and approvals below apply to the basic Gamewell Voice fire phone accessories. In some cases, certain modules may not be listed by certain approval agencies, or listing may be in process. Consult factory for latest listing status. • UL Listed: file S5661. • MEA approved. • CSFM approved. g2512tc.jpg g2512fs.jpg MX-FH MX-FS / MX-WS MX-TC (shown with 6 MX-FH) Ordering Information MX-FJ MX-FH MX-TC Fire phone jack, brushed stainless steel, single-gang plate. Fire phone handset, portable, red (6 mount in MX-TC cabinet). Fire phone handset cabinet, holds 6 MX-FH portable handsets, charcoal gray cabinet. Cabinet is surface- or semi-flush mount, with key lock, 27.0" H x 14.5" W x 4.0" D (cm: 68.58 H x 36.83 W x 10.16 D). Same as above but red cabinet. Fire phone station, coil cord/thumb-turn latch, red cabinet (surface- or semi-flush mount, 12.75" H x 7.25" W x 3.75" D, cm: 32.385 H x 18.415 W x 9.525 D). Warden station, armored cable/thumb-turn latch, red cabinet (surface- or semi-flush mount 12.75" H x 7.25" W x 3.75" D, cm: 32.385 H x 18.415 W x 9.525 D). CS-2512 09/01/06 Page 1 of 2 MX-TCR MX-FS MX-FJ MX-WS Gamewell Voice: Fire Phone Accessories g2512fj.jpg g2512fh.jpg Wiring Diagram g2512wir.tif Gamewell-FCI 12 Clintonville Road Northford, CT 06472-1610 Phone: 203-484-7161 Fax: 203-484-7118 www.gamewell-fci.com A Honeywell Company © 2006 Gamewell-FCI Specifications and wiring information are provided for information only and are believed to be accurate. Gamewell-FCI assumes no responsibility for their use. Data and design are subject to change without notice. Installation and wiring instructions shipped with the product shall always be used for actual installation. For more information, contact Gamewell-FCI. Page 2 of 2 Gamewell Voice: Fire Phone Accessories CS-2512 09/01/06
