S1J

S1A THRU S1M SURFACE MOUNT RECTIFIER Reverse Voltage - 50 to 1000 Volts DO-214AC Forward Current - 1.0 Ampere FEATURES ♦ Plastic package has Underwriters Laboratory Flammability Classification 94V-0 ♦ For surface mounted applications ♦ Low profile package ♦ Built-in strain relief, ideal for automated placement ♦ Glass passivated chip junction ♦ High temperature soldering: 250°C/10 seconds at terminals 0.065 (1.65) 0.049 (1.25) 0.110 (2.79) 0.100 (2.54) 0.177 (4.50) 0.157 (3.99) 0.012 (0.305) 0.006 (0.152) 0.090 (2.29) 0.078 (1.98) MECHANICAL DATA Case: JEDEC DO-214AC molded plastic over passivated chip Terminals: Solder plated, solderable per MIL-STD-750, Method 2026 Polarity: Color band denotes cathode end Weight: 0.002 ounce, 0.064 gram 0.060 (1.52) 0.030 (0.76) 0.008 (0.203) MAX. 0.208 (5.28) 0.194 (4.93) Dimensions are in inches and (millimeters) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Ratings at 25°C ambient temperature unless otherwise specified. SYMBOLS S1A SA S1B SB S1D SD S1G SG S1J SJ S!K SK S1M SM UNITS Device marking code Maximum recurrent peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current See Figure 1 Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method) TL=110°C Maximum instantaneous forward voltage at 1.0A Maximum DC reverse current at Rated DC blocking voltage Typical reverse recovery time (NOTE 1) Typical junction capacitance (NOTE 2) Typical thermal resistance (NOTE 3) Operating junction and storage temperature range TA=25°C TA=125°C VRRM VRMS VDC I(AV) 50 35 50 100 70 100 200 140 200 400 280 400 1.0 600 420 600 800 560 800 1000 700 1000 Volts Volts Volts Amp IFSM VF IR trr CJ RΘJA RΘJL TJ, TSTG 40.0 1.10 1.0 50.0 1.8 12.0 75.0 27.0 -55 to +150 30.0 Amps Volts 5.0 µA µs pF 85.0 30.0 °C/W °C NOTES: (1) Reverse recovery test conditions: IF=0.5A, IR=1.0A, Irr=0.25A (2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts (3) Thermal resistance from junction to ambient and from junction to lead mounted on 0.2 x 0.2” (5.0 x 5.0mm) copper pad areas 4/98 RATING AND CHARACTERISTIC CURVES S1A THRU S1M FIG. 1 - FORWARD CURRENT DERATING CURVE AVERAGE FORWARD CURRENT, AMPERES FIG. 2 - MAXIMUM NON-REPETITIVE PEAK FORWARD SURGE CURRENT 1.2 RESISTIVE OR INDUCTIVE LOAD 100 PEAK FORWARD SURGE CURRENT, AMPERES 1.0 S1(A-J) TL=110°C 8.3ms SINGLE HALF SINE-WAVE (JEDEC Method) 0.8 S1(K,M) S1(A-J) 0.6 0.4 0.2 0 0.2 x 0.2” (5.0 x 5.0mm) THICK COPPER PAD AREAS 10 S1(K,M) 0 20 40 60 80 100 120 140 160 LEAD TEMPERATURE, °C 1 1 10 NUMBER OF CYCLES AT 60 HZ 100 FIG. 3 - TYPICAL INSTANTANEOUS FORWARD CHARACTERISTICS FIG. 4 - TYPICAL REVERSE CHARACTERISTICS 100 100 INSTANTANEOUS FORWARD CURRENT, AMPERES INSTANTANEOUS REVERSE CURRENT, MICROAMPERES 10 TJ=25°C 10 TJ=125°C 1 1 TJ=75°C 0.1 PULSE WIDTH=300µs 1% DUTY CYCLE 0.1 TJ=25°C 0.01 0.01 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 0.001 0 20 40 60 80 100 PERCENT OF RATED PEAK REVERSE VOLTAGE, % INSTANTANEOUS FORWARD VOLTAGE, VOLTS FIG. 5 - TYPICAL JUNCTION CAPACITANCE TRANSIENT THERMAL IMPEDANCE, °C/W FIG. 6 - TRANSIENT THERMAL IMPEDANCE 100 JUNCTION CAPACITANCE, pF 1,000 TJ=25°C f=1.0 MHZ Vsig=50mVp-p 100 S1(K,M) 10 S1(A-J) 10 UNITS MOUNTED on 0.20 x 0.20” (5.0 x 5.0mm) x 0.5 mil. INCHES (0.013mm) THICK COPPER LAND AREAS 1 0.01 0.1 1 10 100 REVERSE VOLTAGE, VOLTS 1 0.01 0.1 1 t, PULSE DURATION, 10 100
