100-003-B203L

100-003 Tubular Metal Braid ASTM B355 Class 4 OFHC Nickel Plated Copper for EMI Shielding Applications EMI Shielding Accessories Product Series Wire Gauge A - 36 AWG (Table I) B - 34 AWG (Table II) Basic Number Lanyard (Omit for None) 100 - 003 - A 203 Dash Number (See Table I or 2) L I.D. Lanyard (Synthetic Fiber) Minimum Order Length is 100 Feet (30.5M) APPLICATION NOTES 1. Consult factory for sizes not shown 2. Metric dimensions (mm) are indicated in parentheses. 3. Direct current ratings are given for information only. Values shown are for uninsulated braid in free air at 86°F (30°C). Actual values will depend on permissible temperature rise, voltage drop and other conditions of service. Values should be de-rated if the braid is insulated or in close contact with other components. H © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-26 for EMI Shielding Applications Dash No. 031 062 078 109 125 156 171 188 203 250 375 500 562 625 781 937 1000 1250 1375 1500 2000 2500 Fractional Equivalent 1/32 1/16 5/64 7/64 1/8 5/32 11/64 3/16 13/64 1/4 3/8 1/2 9/16 5/8 25/32 15/16 1 1 1/4 1 3/8 1 1/2 2 2 1/2 Nominal I.D. .031 (.8) .062 (1.6) .078 (2.0) .109 (2.8) .125 (3.2) .156 (4.0) .171 (4.3) .188 (4.8) .203 (5.2) .250 (6.4) .375 (9.5) .500 (12.7) .562 (14.3) .625 (15.9) .781 (19.8) .937 (23.8) 1.000 (25.4) 1.250 (31.8) 1.375 (34.9) 1.500 (38.1) 2.000 (50.8) 2.500 (63.5) TABLE I (36 AWG) No. of No. of Carriers Ends 24 24 48 24 72 24 96 24 120 24 240 24 168 24 192 24 312 24 384 24 384 48 528 48 624 48 720 48 864 48 640 64 768 64 792 72 864 72 936 72 1152 96 1248 96 Current Rating Amps 7.0 11.0 16.0 19.0 25.0 40.0 32.0 33.0 46.0 53.0 53.0 62.0 73.0 85.0 88.0 65.0 90.0 Lbs./100 Ft. (Kg/30.5M) .20 (.09) .40 (.18) .60 (.27) .83 (.38) 1.03 (.47) 2.09 (.95) 1.43 (.65) 1.63 (.74) 2.80 (1.27) 3.45 (1.56) 3.95 (1.79) 4.77 (2.16) 5.00 (2.27) 5.94 (2.69) 7.35 (3.33) 5.83 (2.64) 7.50 (3.40) Dash No. 062 109 125 171 203 375 437 500 781 1000 1250 Fractional Equivalent 1/16 7/64 1/8 11/64 13/64 3/8 7/16 1/2 25/32 1 1 1/4 TABLE II (34 AWG) No. of Nominal No. of Carriers Ends I.D. 16 .062 (1.6) 32 16 .109 (2.8) 64 24 .125 (3.2) 72 24 .171 (4.3) 120 24 .203 (5.2) 192 48 .375 (9.5) 240 48 .437 (11.1) 288 48 .500 (12.7) 336 48 .781 (19.8) 528 64 1.000 (25.4) 576 72 1.250 (31.8) 648 Current Rating Amps 11.0 19.0 19.0 36.0 46.0 53.0 44.2 62.0 88.0 150.0 Lbs./100 Ft. (Kg/30.5M) .43 (.20) .82 (.37) .92 (.42) 1.56 (.71) 2.79 (1.27) 3.27 (1.48) 3.93 (1.78) 4.77 (2.16) 7.14 (3.24) 7.33 (3.33) © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-27 EMI Shielding Accessories 100-003 Tubular Metal Braid ASTM B355 Class 4 OFHC Nickel Plated Copper H
