100-041-04T5A

100-041 Tapered Tubular Metal Braid Nickel/Copper, Silver/Copper or Tin/Copper for Series 72 & 74 Tubing and Series 75 Conduit Braiding 100-041-06 N 5 A Product Series Dash No. (Table I or II) Material N = Nickel/Copper S = Silver/Copper T = Tin/Copper A = 36 AWG (Omit for 34 AWG) Length in 1 inch increments Order Length 5.0 (127.0) Minimum 12.0 (304.8) Maximum 3.0 (76.2) Min. Dash no.'s 02-12 flared or folded back in this area. A B Dash No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 + .10 - .00 .30 .45 .60 .75 .75 1.05 1.05 1.20 1.20 1.50 1.50 1.50 .88 1.38 TABLE I A (2.5) (0.0) (7.6) (11.4) (15.2) (19.1) (19.1) (26.7) (26.7) (30.5) (30.5) (38.1) (38.1) (38.1) (22.4) (35.1) B + .10 - .00 .15 .30 .30 .30 .50 .50 .75 .75 1.00 .75 1.00 1.20 .50 .75 (2.5) (0.0) (3.8) (7.6) (7.6) (7.6) (12.7) (12.7) (19.1) (19.1) (25.4) (19.1) (25.4) (30.5) (12.7) (19.1) Consult with the factory for custom tapered braid configurations. Metric dimensions (mm) are indicated in parentheses. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com H-4
