102-002-024

Expandable Fabric Tubular Braided Sleeving for Series 72 & 74 Tubing and Series 75 Conduit 102-001-008 Product Series (Table I) Dash No. (Table II) Minimum Order Length is 100 Feet (30.5M) B A Before Expansion After Expansion Product Series 102-001 102-002 102-020 102-021 102-022 102-023 Material Polyethylene Terephthalate Polyethylene Terephthalate E-CTFE * (EthyleneChlorotrifluorethylene) E-CTFE * (EthyleneChlorotrifluorethylene) E-CTFE * (EthyleneChlorotrifluorethylene) E-CTFE * (EthyleneChlorotrifluorethylene) TABLE I Material Material Dia. Color .010 (0.25) White .010 (0.25) .011 (0.28) .011 (0.28) .011 (0.28) .011 (0.28) Black White with Black Tracer Black Black with White Tracer White Wall Thickness Nominal .025 (0.6) .025 (0.6) .030 (0.8) .030 (0.8) .030 (0.8) .030 (0.8) Temperature Range -65°F [-54°C] to +250°F [+121°C] -65°F [-54°C] to +250°F [+121°C] -100°F [-73°C] to +302°F [+150°C] -100°F [-73°C] to +302°F [+150°C] -100°F [-73°C] to +302°F [+150°C] -100°F [-73°C] to +302°F [+150°C] * Note: The trade name for E-CTFE is Halar. TABLE II Dash Nom A Dia No. Dia Min 004 .125 (3.2) .090 (2.3) 008 .250 (6.4) .125 (3.2) 016 .500 (12.7) .250 (6.4) 024 .750 (19.1) .500 (12.7) 040 1.250 (31.8) .750 (19.1) Consult factory for sizes not shown B Dia Max .250 (6.4) .375 (9.5) .750 (19.1) 1.250 (31.8) 1.500 (38.1) Spec Max Weight in Lbs. Per 100 Feet [Kg/30.5] 102-001, 102-020, 102-021, 102-002 102-022, 102-023 .17 [0.08] .29 [0.13] .26 [0.12] .39 [0.18] .78 [0.35] 1.17 [0.53] 1.20 [0.54] 1.81 [0.82] 1.60 [0.73] 2.56 [1.16] Metric dimensions (mm) are indicated in parentheses. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com H-5 Braiding 102-001
