102-051-040

Composite Shielding for Series 74 Convoluted Tubing 102-051 PEEK Tubular Braid (Black) Product Series A 102 - Braided Shielding 102 - 051 008 Tubular Braid Size (See Table I) B Specify Length on Purchase Order. No Minimums! C Wire Bundle Accommodation Range (Ref) I.D. D TABLE I: TUBULAR BRAID SIZE ORDER NUMBER Wire Bundle Accommodation Range Ref. Braid Nominal Size I.D. Min. Max. 004 .125 (3.2) .125 (3.2) .312 (7.9) 008 .250 (6.4) .250 (6.4) .500 (12.7) 016 .500 (12.7) .375 (9.5) .719 (18.3) 024 .750 (19.1) .500 (12.7) 1.000 (25.4) 040 1.250 (31.8) .750 (19.1) 1.250 (31.8) E F 1. APPLICATION NOTES Metric dimensions (mm) are in parentheses and are for reference only. G © 2009 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-4
