103-027-016

103-027 75% / 25% AmberStrand® Composite / NiCu Braid for EMI Shielding Applications TABLE I Dash Number 004 008 012 016 020 024 032 040 048 064 Nominal I.D. (Ref.) .125 (3.2) .250 (6.4) .375 (9.5) .500 (12.7) .625 (15.9) .750 (19.1) 1.000 (25.4) 1.250 (31.8) 1.500 (38.1) 2.000 (50.8) Ref. Wire Bundle Range .093 (2.4) .140 (3.5) .125 (3.2) .312 (7.9) .250 (6.4) .437 (11.1) .250 (6.4) .375 (15.0) .375 (9.5) .700 (17.8) .500 (12.7) .830 (21.1) .780 (19.8) 1.100 (27.94) .938 (23.8) 1.312 (33.3) 1.187 (30.1) 1.590 (40.37) 1.312 (33.3) 2.090 (53.08) Approximate Grams Per Foot 1.5 2.4 3.9 6.0 6.4 7.2 11.0 15.0 25.2 32.0 Carrier Breakdown 16 - AmberStrand® 4 - Nickel Copper 24 - AmberStrand® 8 - Nickel Copper 36 - AmberStrand® 12 - Nickel Copper 54 - AmberStrand® 18 - Nickel Copper 54 - AmberStrand® 18 - Nickel Copper 72 - AmberStrand® 24 - Nickel Copper 48 - AmberStrand® 16 - Nickel Copper 72 - AmberStrand® 24 - Nickel Copper 72 - AmberStrand® 24 - Nickel Copper 72 - AmberStrand® 24 - Nickel Copper Product Series 103 - Braided Shielding Dash Number 103 - 027 - 024 75%/25% Blended AmberStrand® Composite / NiCu Braid Specify Length on Purchase Order. No Minimums! Wire Bundle Accommodation Range (Ref) I.D. APPLICATION NOTES 1. 2. Marking - Label individual packages. Material - Nickel Clad/Thermoplastic, silver color. Nickel plated Copper wire/ASTM B355 CL.7 OFHC, 36 awg Braid angle all sizes 40° - 50° Consult factory for alternative blend ratios. Braid is made from Nickel-plated AmberStrand® composite thermoplastic fibers. AmberStrand® is a registered trademark of Syscom Advanced Materials, Inc. Metric dimensions (mm) are in parenthesis and for reference only. 3. 4. 5. © 2009 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-3 Composite Shielding A B C D E F G
