120-100-2-2-28BF

120-100 Series 74 Helical Convoluted Tubing (MIL-T-81914) Natural or Black PFA, FEP, PTFE, Tefzel® (ETFE) or PEEK Type A - Tubing Only - No Braid 120-100-1-1-16 B E Product Series Basic Number Class 1 = Standard Wall 2 = Thin Wall (See Note 1) Convolution 1 = Standard 2 = Close Material E = ETFE F = FEP P = PFA T = PTFE (See Note 2) K = PEEK (See Note 3) B = Black C = Natural Dash Number (Table I) Conduit and Conduit Systems TUBING ONLY NO BRAID TYPE A Length (As Specified In Feet) A DIA B DIA MINIMUM BEND RADIUS TABLE I: TUBING SIZE Dash No. 06 09 10 12 14 16 20 24 28 32 40 48 56 64 Fractional Size Ref 3/16 9/32 5/16 3/8 7/16 1/2 5/8 3/4 7/8 1 1-1/4 1-1/2 1-3/4 2 A Inside Dia Min .181 (4.6) .273 (6.9) .306 (7.8) .359 (9.1) .427 (10.8) .480 (12.2) .603 (15.3) .725 (18.4) .860 (21.8) .970 (24.6) 1.205 (30.6) 1.437 (36.5) 1.688 (42.9) 1.937 (49.2) B Dia Max .320 (8.1) .414 (10.5) .450 (11.4) .510 (13.0) .571 (14.5) .650 (16.5) .770 (19.6) .930 (23.6) 1.073 (27.3) 1.226 (31.1) 1.539 (39.1) 1.832 (46.5) 2.156 (54.8) 2.332 (59.2) Minimum Bend Radius .500 (12.7) .750 (19.1) .750 (19.1) .880 (22.4) 1.000 (25.4) 1.250 (31.8) 1.500 (38.1) 1.750 (44.5) 1.880 (47.8) 2.250 (57.2) 2.750 (69.9) 3.250 (82.6) 3.630 (92.2) 4.250 (108.0) APPLICATION NOTES 1. Consult factory for thin-wall, close convolution combination. 2. Consult factory for PTFE maximum lengths. 3. Consult factory for PEEK min/max dimensions. 4. Metric dimensions (mm) are in parentheses. © 2006 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. www.glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com J-2
