120-144-48SN

Series 72 Guardian How To Order Standard Black and Natural/Clear Annular Convoluted Tubing Blue, Yellow, Red, Desert Tan, and Orange Annular Convoluted Tubing Dash No 09 12 16 20 24 28 32 40 48 52 A TyP 120-144 Annular Convoluted tubing For non-environmental and non-EMI/RFI applications—split versions available Product Series Dash No. (Table I) Color Option Table III (Omit for Std. Black) 120 - 144 - 16 Basic No. Y R S S = Slit, Type II (Omit for Standard, Type I, Without Slit) Tubing Option (Table II) table i - dash number/diameter A Inside Dia B Outside Dia Min Max Min Max .24 (6.1) .28 (7.1) .38 (9.7) .42 (10.7) .33 (8.4) .37 (9.4) .48 (12.2) .52 (13.2) .45 (11.4) .50 (12.7) .60 (15.2) .66 (16.8) .57 (14.5) .62 (15.7) .71 (18.0) .77 (20.0) .69 (17.5) .75 (19.1) .88 (22.4) .94 (23.9) .81 (20.6) .87 (22.1) 1.00 (25.4) 1.08 (27.4) .93 (23.6) 1.00 (25.4) 1.12 (28.4) 1.20 (30.5) 1.18 (30.0) 1.25 (31.8) 1.36 (34.5) 1.44 (36.6) 1.43 (36.3) 1.50 (38.1) 1.63 (41.4) 1.71 (43.4) 1.56 (39.6) 1.63 (41.4) 1.77 (45.0) 1.85 (47.0) table ii - tubing option Y V S Kynar/Thermally stabilized PVDF/Not thermally stabilized Siltem/Medium duty table iii - Color option N R Y BL TN O Natural/Clear Red (available in Kynar and PVDF only) Yellow (available in Kynar and PVDF only) Blue (available in Kynar and PVDF only) Desert Tan (available in Kynar and PVDF only) Orange (available in Kynar and PVDF only) Omit for standard black B TyP Standard Packaging Dash No (i.D.) 09 (.281”) 12 (.375”) 16 (.5”) 20 (.625”) 24 (.75”) 32 (1”) 40 (1.25”) 48 (1.5”) 52 (1.625”) max. Length 2000 ft. 1500 ft. 1000 ft. 700 ft. 500 ft. 300 ft. 200 ft. 200 ft. 200 ft. LENGTH (AS SPECIFIED IN P.O.) Packaging Long-length orders of conduit are subject to the practical limits of shipping box sizes. For example, the maximum length of 1/2 inch (dash 16) conduit that can fit in a standard shipping container is 1000 feet. Unless otherwise specified, Glenair standard practice is to ship optimal lengths of conduit material based on tubing diameter and box size. Consult factory for non-standard length or packaging requirements. CAGE Code 06324 Printed in U.S.A. ©2011 Glenair, Inc. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 10
