121-003-12

121-003 Type C Series 72 Annular Convoluted Tubing Thermally Stabilized Kynar® 121-003-16 Product Series Basic No. Dash No. (Table I) TYPE C EXTERNAL TIN/COPPER BRAID LENGTH (AS SPECIFIED IN FEET) A DIA B DIA TIN/COPPER SHIELD MINIMUM BEND RADIUS TABLE I DASH NO. 09 12 16 20 24 28 32 40 A DIA MIN .24 (6.1) .33 (8.4) .45 (11.4) .57 (14.5) .69 (17.5) .81 (20.6) .93 (23.6) 1.18 (30.0) MAX .28 (7.1) .37 (9.4) .50 (12.7) .62 (15.7) .75 (19.1) .87 (22.1) 1.00 (25.4) 1.25 (31.8) B DIA MIN .42 (10.7) .52 (13.2) .64 (16.3) .75 (19.1) .92 (23.4) 1.04 (26.4) 1.16 (29.5) 1.40 (35.6) MAX .46 (11.7) .56 (14.2) .70 (17.8) .81 (20.6) .98 (24.9) 1.12 (28.4) 1.24 (31.5) 1.48 (37.6) MINIMUM BEND RADIUS .75 (19.1) 1.00 (25.4) 1.38 (35.1) 1.69 (42.9) 1.88 (47.8) 2.00 (50.8) 2.38 (60.5) 2.88 (73.2) Metric dimensions (mm) are in parentheses. Note: Tubing supplied in random lengths. For specific size lengths, consult factory. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com E-5 Series 72 Convoluted Tubing
