121-007-24H

121-007 Type D Series 72 Annular Convoluted Tubing Thermally Stabilized Kynar® Series 72 Convoluted Tubing TYPE D INTERNAL TIN/COPPER BRAID EXTERNAL JACKET 121-007-16 H Product Series Basic No. Dash No. (Table I) Jacket Material: E = EPDM H = Hypalon® N = Neoprene V = Viton JACKET SHIELD A DIA B DIA LENGTH (AS SPECIFIED IN FEET) MINIMUM BEND RADIUS TABLE I DASH NO. 09 12 16 20 24 28 32 40 A DIA MIN .24 (6.1) .33 (8.4) .45 (11.4) .57 (14.5) .69 (17.5) .81 (20.6) .93 (23.6) 1.18 (30.0) MAX .28 (7.1) .37 (9.4) .50 (12.7) .62 (15.7) .75 (19.1) .87 (22.1) 1.00 (25.4) 1.25 (31.8) B DIA MIN MAX .54 (13.7) .58 (14.7) .64 (16.3) .68 (17.3) .76 (19.3) .82 (20.8) .87 (22.1) .93 (23.6) 1.04 (26.4) 1.10 (27.9) 1.16 (29.5) 1.24 (31.5) 1.28 (32.5) 1.36 (34.5) 1.52 (38.6) 1.60 (40.6) MINIMUM BEND RADIUS .75 (19.1) 1.00 (25.4) 1.38 (35.1) 1.69 (42.9) 1.88 (47.8) 2.00 (50.8) 2.38 (60.5) 2.88 (73.2) Metric dimensions (mm) are in parentheses. Note: Tubing supplied in random lengths. For specific size lengths, consult factory. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com E-6
