121-100

121-100 Series 74 Helical Convoluted Tubing (AMS-T-81914) Type C: Convoluted Tubing with External Shield and Jacket EXTERNAL SHIELD AND JACKET Series 74 TYPE C Product Series 121 - Convoluted Tubing Class 1 - Standard Wall 2 - Thin Wall2 Tubing Size (See Table I) Material K - PEEK4 E - ETFE F - FEP P - PFA T - PTFE3 Jacket E - EPDM N - Neoprene H - Hypalon® V - Viton 121 - 100 - 1 - 1 - 16 Basic Part Number Convolution 1 - Standard 2 - Close B K T H Color B - Black C - Natural Shield A - Composite AmberStrand® C - Stainless Steel N - Nickel/Copper S - SnCuFe T - Tin/Copper JACKET SHIELD TUBING A DIA B DIA LENGTH (AS SPECIFIED IN FEET) MINIMUM BEND RADIUS TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS MINIMUM TUBING FRACTIONAL A INSIDE B DIA BEND RADIUS SIZE SIZE REF DIA MIN MAX .50 (12.7) 06 3/16 .181 (4.6) .490 (12.4) .75 (19.1) 09 9/32 .273 (6.9) .584 (14.8) .75 (19.1) 10 5/16 .306 (7.8) .620 (15.7) .88 (22.4) 12 3/8 .359 (9.1) .680 (17.3) 1.00 (25.4) 14 7/16 .427 (10.8) .741 (18.8) 1.25 (31.8) 16 1/2 .480 (12.2) .820 (20.8) 1.50 (38.1) 20 5/8 .603 (15.3) .940 (23.9) 1.75 (44.5) 24 3/4 .725 (18.4) 1.100 (27.9) 1.88 (47.8) 28 7/8 .860 (21.8) 1.243 (31.6) 2.25 (57.2) 32 1 .970 (24.6) 1.396 (35.5) 2.75 (69.9) 40 1 1/4 1.205 (30.6) 1.709 (43.4) 3.25 (82.6) 48 1 1/2 1.437 (36.5) 2.002 (50.9) 3.63 (92.2) 56 1 3/4 1.688 (42.9) 2.327 (59.1) 4.25 (108.0) 64 2 1.937 (49.2) 2.502 (63.6) © 2009 Glenair, Inc. CAGE Code 06324 APPLICATION NOTES 1. Metric dimensions (mm) are in parentheses and are for reference only. Consult factory for thinwall, close convolution combination. For PTFE maximum lengths - consult factory. Consult factory for PEEKTM min/max dimensions. 2. 3. 4. Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-9 Convoluted Tubing A B C D E F G
