121-101-2-2-32BPC

Convoluted Tubing 121-101 Series 74 Helical Convoluted Tubing (AMS-T-81914) Type D: Convoluted Tubing with Single External Shield A Product Series 121 - Convoluted Tubing Class 1 - Standard Wall 2 - Thin Wall2 Tubing Size (See Table I) Material K - PEEK4 E - ETFE F - FEP P - PFA T - PTFE3 Series 74 TYPE D T 121 - 101 - 1 - 1 - 16 B K EXTERNAL SHIELD B Basic Part Number Convolution 1 - Standard 2 - Close Color B - Black C - Natural Shield A - Composite AmberStrand® C - Stainless Steel N - Nickel/Copper S - SnCuFe T - Tin/Copper SHIELD C A DIA TUBING B DIA D LENGTH (AS SPECIFIED IN FEET) MINIMUM BEND RADIUS E F TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS TUBING FRACTIONAL A INSIDE B DIA MINIMUM SIZE SIZE REF DIA MIN MAX BEND RADIUS 06 3/16 .181 (4.6) .370 (9.4) .50 (12.7) 09 9/32 .273 (6.9) .464 (11.8) .75 (19.1) 10 5/16 .306 (7.8) .500 (12.7) .75 (19.1) 12 3/8 .359 (9.1) .560 (14.2) .88 (22.4) 14 7/16 .427 (10.8) .621 (15.8) 1.00 (25.4) 16 1/2 .480 (12.2) .700 (17.8) 1.25 (31.8) 20 5/8 .603 (15.3) .820 (20.8) 1.50 (38.1) 24 3/4 .725 (18.4) .980 (24.9) 1.75 (44.5) 28 7/8 .860 (21.8) 1.123 (28.5) 1.88 (47.8) 32 1 .970 (24.6) 1.276 (32.4) 2.25 (57.2) 40 1 1/4 1.205 (30.6) 1.589 (40.4) 2.75 (69.9) 48 1 1/2 1.437 (36.5) 1.882 (47.8) 3.25 (82.6) 56 1 3/4 1.688 (42.9) 2.132 (54.2) 3.63 (92.2) 64 2 1.937 (49.2) 2.382 (60.5) 4.25 (108.0) APPLICATION NOTES 1. Metric dimensions (mm) are in parentheses and are for reference only. Consult factory for thinwall, close convolution combination. For PTFE maximum lengths - consult factory. Consult factory for PEEKTM min/max dimensions. 2. 3. 4. G © 2009 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-10
