121-102-2-2-BKA

121-102 Series 74 Helical Convoluted Tubing (AMS-T-81914) Type E: Convoluted Tubing with Two External Shields Series 74 TYPE E TWO EXTERNAL SHIELDS Product Series 121 - Convoluted Tubing Class 1 - Standard Wall 2 - Thin Wall2 Tubing Size (See Table I) Material K - PEEK4 E - ETFE F - FEP P - PFA T - PTFE3 Outer Shield A - Composite AmberStrand® C - Stainless Steel N - Nickel/Copper S - SnCuFe T - Tin/Copper 121 - 102 - 1 - 1 - 16 Basic Part Number Convolution 1 - Standard 2 - Close B K T H Color B - Black C - Natural Inner Shield A - Composite AmberStrand® N - Nickel/Copper S - SnCuFe T - Tin/Copper Outer Shield Inner Shield Tubing A DIA B DIA Length (As Specified in Feet) MINIMUM BEND RADIUS TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS TUBING FRACTIONAL A INSIDE B DIA MINIMUM SIZE SIZE REF DIA MIN MAX BEND RADIUS * 06 3/16 .181 (4.6) .420 (10.7) .50 (12.7) 09 9/32 .273 (6.9) .514 (13.1) .75 (19.1) 10 5/16 .306 (7.8) .550 (14.0) .75 (19.1) 12 3/8 .359 (9.1) .610 (15.5) .88 (22.4) 14 7/16 .427 (10.8) .671 (17.0) 1.00 (25.4) 16 1/2 .480 (12.2) .750 (19.1) 1.25 (31.8) 20 5/8 .603 (15.3) .870 (22.1) 1.50 (38.1) 24 3/4 .725 (18.4) 1.030 (26.2) 1.75 (44.5) 28 7/8 .860 (21.8) 1.173 (29.8) 1.88 (47.8) 32 1 .970 (24.6) 1.326 (33.7) 2.25 (57.2) 40 1 1/4 1.205 (30.6) 1.639 (41.6) 2.75 (69.9) 48 1 1/2 1.437 (36.5) 1.932 (49.1) 3.25 (82.6) 56 1 3/4 1.688 (42.9) 2.182 (55.4) 3.63 (92.2) 64 2 1.937 (49.2) 2.432 (61.8) 4.25 (108.0) *The minimum bend radius is based on Type A construction. For multiple-braided coverings, these minimum bend radii may be increased slightly. © 2009 Glenair, Inc. CAGE Code 06324 APPLICATION NOTES 1. Metric dimensions (mm) are in parentheses and are for reference only. Consult factory for thinwall, close convolution combination. For PTFE maximum lengths - consult factory. Consult factory for PEEKTM min/max dimensions. 2. 3. 4. Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-11 Convoluted Tubing A B C D E F G
