121-103-1-1-32BKA

Convoluted Tubing 121-103 Series 74 Helical Convoluted Tubing (AMS-T-81914) Type F: Convoluted Tubing with Jacket and Two Shields Material K - PEEK4 E - ETFE F - FEP P - PFA T - PTFE3 Outer Shield A - Composite AmberStrand® C - Stainless Steel N - Nickel/Copper S - SnCuFe T - Tin/Copper A Product Series 121 - Convoluted Tubing Class 1 - Standard Wall 2 - Thin Wall2 Tubing Size (See Table I) Series 74 TYPE F JACKET AND TWO EXTERNAL SHIELDS 121 - 103 - 1 - 1 - 16 B K T S H Jacket E - EPDM N - Neoprene H - Hypalon® V - Viton B Basic Part Number Convolution 1 - Standard 2 - Close Color B - Black C - Natural Inner Shield A - Composite AmberStrand® N - Nickel/Copper S - SnCuFe T - Tin/Copper C A DIA JACKET OUTER SHIELD INNER SHIELD TUBING B DIA MINIMUM BEND RADIUS D LENGTH (AS SPECIFIED IN FEET) E F TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS TUBING FRACTIONAL A INSIDE B DIA MINIMUM SIZE SIZE REF DIA MIN MAX BEND RADIUS * 06 3/16 .181 (4.6) .540 (13.7) .50 (12.7) 09 9/32 .273 (6.9) .634 (16.1) .75 (19.1) 10 5/16 .306 (7.8) .670 (17.0) .75 (19.1) 12 3/8 .359 (9.1) .730 (18.5) .88 (22.4) 14 7/16 .427 (10.8) .791 (20.1) 1.00 (25.4) 16 1/2 .480 (12.2) .870 (22.1) 1.25 (31.8) 20 5/8 .603 (15.3) .990 (25.1) 1.50 (38.1) 24 3/4 .725 (18.4) 1.150 (29.2) 1.75 (44.5) 28 7/8 .860 (21.8) 1.293 (32.8) 1.88 (47.8) 32 1 .970 (24.6) 1.446 (36.7) 2.25 (57.2) 40 1 1/4 1.205 (30.6) 1.759 (44.7) 2.75 (69.9) 48 1 1/2 1.437 (36.5) 2.052 (52.1) 3.25 (82.6) 56 1 3/4 1.688 (42.9) 2.302 (58.5) 3.63 (92.2) 64 2 1.937 (49.2) 2.552 (64.8) 4.25 (108.0) *The minimum bend radius is based on Type A construction. For multiple-braided coverings, these minimum bend radii may be increased slightly. APPLICATION NOTES 1. Metric dimensions (mm) are in parentheses and are for reference only. Consult factory for thinwall, close convolution combination. For PTFE maximum lengths consult factory. Consult factory for PEEKTM min/max dimensions. 2. 3. 4. G © 2009 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-12
