123-100-1-1-06BEE_09

123-100 Series 74 Helical Convoluted Tubing (AMS-T-81914) Type G: Convoluted Tubing with Jacket Series 74 TYPE G EXTERNAL JACKET Product Series 123 - Convoluted Tubing Class 1 - Standard Wall 2 - Thin Wall2 Tubing Size (See Table I) Material K - PEEK4 E - ETFE F - FEP P - PFA T - PTFE3 123 - 100 - 1 - 1 - 16 Basic Part Number Convolution 1 - Standard 2 - Close B K H Jacket E - EPDM N - Neoprene H - Hypalon® V - Viton Color B - Black C - Natural JACKET TUBING A DIA B DIA LENGTH (AS SPECIFIED IN FEET) MINIMUM BEND RADIUS TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS TUBING FRACTIONAL A INSIDE B DIA MINIMUM SIZE SIZE REF DIA MIN MAX BEND RADIUS 06 3/16 .181 (4.6) .460 (11.7) .50 (12.7) 09 9/32 .273 (6.9) .554 (14.1) .75 (19.1) 10 5/16 .306 (7.8) .590 (15.0) .75 (19.1) 12 3/8 .359 (9.1) .650 (16.5) .88 (22.4) 14 7/16 .427 (10.8) .711 (18.1) 1.00 (25.4) 16 1/2 .480 (12.2) .790 (20.1) 1.25 (31.8) 20 5/8 .603 (15.3) .910 (23.1) 1.50 (38.1) 24 3/4 .725 (18.4) 1.070 (27.2) 1.75 (44.5) 28 7/8 .860 (21.8) 1.213 (30.8) 1.88 (47.8) 32 1 .970 (24.6) 1.366 (34.7) 2.25 (57.2) 40 1 1/4 1.205 (30.6) 1.679 (42.6) 2.75 (69.9) 48 1 1/2 1.437 (36.5) 1.972 (50.1) 3.25 (82.6) 56 1 3/4 1.688 (42.9) 2.222 (56.4) 3.63 (92.2) 64 2 1.937 (49.2) 2.472 (62.8) 4.25 (108.0) APPLICATION NOTES 1. Metric dimensions (mm) are in parentheses and are for reference only. Consult factory for thinwall, close convolution combination. For PTFE maximum lengths consult factory. Consult factory for PEEKTM min/max dimensions. 2. 3. 4. © 2009 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-13 Convoluted Tubing A B C D E F G
