123-100-2-2-10CFH

123-100 - Type G Series 74 Helical Convoluted Tubing (MIL-T-81914) Natural or Black PFA, FEP, PTFE, Tefzel® (ETFE) or PEEK 123-100-1-1-16 B E H Product Series Basic No. Class 1 = Standard Wall 2 = Thin Wall * Convolution 1 = Standard 2 = Close Dash No. (Table I) Material E = ETFE F = FEP K = PEEK *** Color B = Black C = Natural P = PFA T = PTFE** Jacket E = EPDM H = Hypalon® N = Neoprene V = Viton TYPE G EXTERNAL JACKET JACKET TUBING A DIA B DIA LENGTH (AS SPECIFIED IN FEET) TABLE I A INSIDE DIA MIN .181 (4.6) .273 (6.9) .306 (7.8) .359 (9.1) .427 (10.8) .480 (12.2) .603 (15.3) .725 (18.4) .860 (21.8) .970 (24.6) 1.205 (30.6) 1.437 (36.5) 1.688 (42.9) 1.937 (49.2) MINIMUM BEND RADIUS DASH FRACTIONAL NO SIZE REF 06 3/16 09 9/32 10 5/16 12 3/8 14 7/16 16 1/2 20 5/8 24 3/4 28 7/8 32 1 40 1 1/4 48 1 1/2 56 1 3/4 64 2 B DIA MAX .460 (11.7) .554 (14.1) .590 (15.0) .650 (16.5) .711 (18.1) .790 (20.1) .910 (23.1) 1.070 (27.2) 1.213 (30.8) 1.366 (34.7) 1.679 (42.6) 1.972 (50.1) 2.222 (56.4) 2.472 (62.8) MINIMUM BEND RADIUS .50 (12.7) .75 (19.1) .75 (19.1) .88 (22.4) 1.00 (25.4) 1.25 (31.8) 1.50 (38.1) 1.75 (44.5) 1.88 (47.8) 2.25 (57.2) 2.75 (69.9) 3.25 (82.6) 3.63 (92.2) 4.25 (108.0) Metric dimensions (mm) are in parentheses. * Consult factory for thin-wall, close convolution combination. ** For PTFE maximum lengths - consult factory. *** Consult factory for PEEK min/max dimensions. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com D-9 Series 74 Convoluted Tubing
