140-103

Composite Junction Boxes Series 140-103 Large Junction Box A Product Series 140 - Composite Boxes Basic Part Number Dash Number B Large Series 140-103 CostSaver Composite Junction Box TABLE II: MATERIAL COLOR & FINISH OPTIONS Sym Material & Color B G – Thermoplastic / Black Thermoplastic / Grey Thermoplastic / NA Finish Options XO and XMS XO and XMS XM, XW and XZN 140 G 103 XMS - 0000 Finish Symbol (See Table I) Material Color Symbol (See Table II) C TABLE I: FINISHES Symbol XO XMS XM XW XZN XMT Finish Description No Plating (Non-Conductive Finish) Internal Surfaces - Electroless Nickel External Surfaces - See Table II All Surfaces – Electroless Nickel All Surfaces – Cadmium Olive Drab over Electroless Nickel All Surfaces – Zinc Nickel/Black 2000 Hour Corrosion Resistant Ni-PTFE, NickelFluorocarbon Polymer. 1000 Hour GreyTM D E TABLE III: KEY DIMENSIONS Box Series Number Large 140-103 External Dimensions 9.10 (231) x 9.10 (231) x 4.50 (114) Internal Dimensions (with Aluminum Mounting Plate Installed, if applicable) 7.87 (200) x 7.87 (200) x 3.78 (96) F 1. 2. 3. NOTES Use Dash Number 0000 for Basic Box with No Additional Options Beyond Your Specified Finish. 0000 Basic Box Includes #6-32 UNC Fasteners. Box Series Numbers are for reference only. Please complete the worksheet on E-14 and call the factory for part number assignment for your specific box configuration. Metric dimensions (mm) are in parenthesis and for reference only G © 2009 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com E-24 Series 140-103 Large Junction Box SIDE A 11.44 (290.60) Max 10.00 (254.0) 9.10 (231.1) 7.00 (177.8) SIDE D 7.00 (177.8) 5.75 (146.1) 9.10 (231.1) Max SIDE B SIDE C Assembly Identified with Manufacturer's Name and Part Number Mounting Hole (4 Places) accommodate 1/4-20 or 6mm Bolt EMI/RFI Tongue and Groove Environmental Seal .62 (15.7) 4.50 (114.3) SIDES A & C Mounting Plate (Optional) Mounting Boss accommodates #6-32 Screw (4 Places) SIDES B & D © 2009 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com E-25 Composite Junction Boxes A B C D E F G
