151-001-1-5

MIL-DTL-55116 Type Audio Connectors 151-001 • M55116/1 – /4 U-229 • MIL-DTL-55116 Type Audio Plugs Field Serviceable with Wire Strain Relief MIL-DTL-55116 type audio plug, field serviceable with wire strain relief These Series 151 MIL-DTL-55116 Type audio plugs are designed for high-reliability, severe environment radio communications equipment. They are available in both 5 pin and 6 pin configurations, with either crimp sleeve or solder cup pogo pin terminals. All feature versatile wire strain relief to protect cable conductors from damage. Shells are made of passivated stainless steel, contacts are gold plated copper alloy. Plug connector contacts are sealed in the unmated condition. Ø .836(21.2) .826 (21.0) .360 (9.14) Ref 1.308 (33.2) .250 (1.35) Ref U-229 Plug, 5 Crimp Contacts Flat In Knurl 1.200 (30.5) Ref No. of Contacts Contact Type Ø Cable ± .010 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 MIL SPEC Part Number M55116/1-1 M55116/1-2 M55116/1-3 M55116/1-4 M55116/1-5 M55116/2-1 M55116/2-2 M55116/2-3 M55116/2-4 M55116/2-5 M55116/3-1 M55116/3-2 M55116/3-3 M55116/3-4 M55116/3-5 M55116/4-1 M55116/4-2 M55116/4-3 M55116/4-4 M55116/4-5 Glenair Part Number 151-001-1-1 151-001-1-2 151-001-1-3 151-001-1-4 151-001-1-5 151-001-2-1 151-001-2-2 151-001-2-3 151-001-2-4 151-001-2-5 151-001-3-1 151-001-3-2 151-001-3-3 151-001-3-4 151-001-3-5 151-001-4-1 151-001-4-2 151-001-4-3 151-001-4-4 151-001-4-5 Mates With U-229 Plug, 6 Crimp Contacts 5 Crimp 151-003-1 151-004-1 151-004-3 6 Crimp U-229 Plug, 5 Solder Cup Contacts 5 Solder Cup 151-003-2 151-004-2 151-004-4 151-003-1 151-004-1 151-004-3 U-229 Plug, 6 Solder Cup Contacts © 2012 Glenair, Inc. 6 Solder Cup 151-003-2 151-004-2 151-004-4 U.S. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 4 E-Mail: sales@glenair.com
