151-002-2-2

151-002 • M55116/5 – /8 U-182 • MIL-DTL-55116 Type Audio Plugs Molded Strain Relief for Overmolding MIL-DTL-55116 type molded audio plug These Series 151 MIL-DTL-55116 Type molded audio plugs are designed for overmolding in cable cordsets for high-reliability, severe environment radio communications equipment, and are not field-serviceable. They are available in 5 pin and 6 pin configurations, with crimp sleeve or solder cup pogo pin terminals. Shells are made of passivated stainless steel, contacts are gold plated copper alloy. Plug connector contacts are sealed in the unmated condition. Ø .836(21.2) .826 (21.0) 1.308 (33.2) Ref .140 (3.56) .110 (2.80) U-182 Plug, 5 Crimp Contacts Flat In Knurl No. of Contacts Contact Type Ø Cable ± .010 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 .165 .228 .250 .290 .320 MIL SPEC Part Number M55116/5-1 M55116/5-2 M55116/5-3 M55116/5-4 M55116/5-5 M55116/6-1 M55116/6-2 M55116/6-3 M55116/6-4 M55116/6-5 M55116/7-1 M55116/7-2 M55116/7-3 M55116/7-4 M55116/7-5 M55116/8-1 M55116/8-2 M55116/8-3 M55116/8-4 M55116/8-5 Glenair Part Number 151-002-1-1 151-002-1-2 151-002-1-3 151-002-1-4 151-002-1-5 151-002-2-1 151-002-2-2 151-002-2-3 151-002-2-4 151-002-2-5 151-002-3-1 151-002-3-2 151-002-3-3 151-002-3-4 151-002-3-5 151-002-4-1 151-002-4-2 151-002-4-3 151-002-4-4 151-002-4-5 Mates With U-182 Plug, 6 Crimp Contacts 5 Crimp 151-003-1 151-004-1 151-004-3 6 Crimp U-182 Plug, 5 Solder Cup Contacts 5 Solder Cup 151-003-2 151-004-2 151-004-4 151-003-1 151-004-1 151-004-3 U-182 Plug, 6 Solder Cup Contacts © 2012 Glenair, Inc. 6 Solder Cup 151-003-2 151-004-2 151-004-4 U.S. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 5 E-Mail: sales@glenair.com MIL-DTL-55116 Type Audio Connectors
