151-003-2

MIL-DTL-55116 Type Audio Connectors 151-003 • M55116/9 – /10 U-183 • MIL-DTL-55116 Type Jam Nut Receptacle MIL-DTL-55116 type audio receptacle, jam nut panel mount These Series 151 MIL-DTL-55116 Type panel mount jam nut receptacles are designed for high-reliability, severe environment communications equipment. They are available in either a 5 pin or 6 pin configuration. Receptacles are equipped with solder cup spring terminals and a jam nut for panel mounting. Shells and nuts are made of passivated stainless steel, contacts are gold plated copper alloy. Receptacle connector contacts are sealed in the unmated condition. .915 (23.2) .905(23.0) Ø .963(24.5) .953 (24.2) .792 .782 .750-20 UNEF-2A .220 (5.60) Ref Ø . 594(15.1) . 590 (15.0) .650 (16.5) .640 (16.3) Ø .765(19.4) .755 (19.2) .077 (2.00) Ref .657 (16.7) .653 (16.6) U-183 Jam Nut Receptacle, 5 Solder Cup Contacts No. of Contacts 5 Contact Type Solder Cup Recommended Panel Hole MIL SPEC Part Number M55116/9-0 Glenair Part Number 151-003-1 Mates With 151-001-1 151-001-3 151-002-1 151-002-3 151-001-2 151-001-4 151-002-2 151-002-4 U-183 Jam Nut Receptacle, 6 Solder Cup Contacts 6 Solder Cup M55116/10-0 151-003-2 © 2012 Glenair, Inc. U.S. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 6 E-Mail: sales@glenair.com
