180-070-6-14-4

Special Environmental Composite Connector for Glenair 181-011 and 181-012 Front Release Termini 180-070 (-6 and -7) 4 Channel Fiber Optic Plug / Receptacle Custom Connector System Product Series Basic Number Insert accommodates Fiber Optic Termini or 16 AWG Electrical Contacts Guide Pins (2 Places) Recommended Panel Cutout .845/.835 (21.5)/(21.2) O .895/.885 (22.7)/(22.5) © 2006 Glenair, Inc. www.glenair.com 180-070-6-14-4 Insert Arrangement Dash Number Shell Size 6 = Plug Assembly 7 = Jam Nut Receptacle Assembly 7/8-20 UNEF-2B Thread Pin Termini Glenair P/N 181012-*** 3.150 (80.0) Max O-Rings .125 (3.2) Typical .343 (8.7) Cable Entry 1.332 (33.8) Max -6 PLUG ASSEMBLY Insert accommodates Fiber Optic Termini or 16 AWG Electrical Contacts Polarizing Key Socket Termini Glenair P/N 181-011-*** O-Ring Panel .156 (4.0) Max .030 (0.8) Min 1.25 (31.8) 1.280 (32.5) Max 1.125 (28.6) Guide Pin Holes (2 Places) 7/8-20 UNEF-2A Thread 1.400 (35.6) Max -7 JAM NUT RECEPTACLE ASSEMBLY Metric dimensions (mm) are in parentheses. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-12
