180-071-NF61

MIL-DTL-38999 Connectors Polarizing Master Key Environment Resistant for Glenair 181-001 and 181-002 Termini 180-071 (-6) Plug Single Channel Fiber Optic Plug Connector 180-071-C 6 1 Product Series Basic Number Finish (Table II) 6 = Plug Assembly Alternate Key Position (1,2,3,4, & 5) (Table I) O-ring .375-.05p-.1L-DS-2B 1.300 (33.0) Max .375-24 UNF-2A O.670 (17.0) Max -6 PLUG ASSEMBLY APPLICATION NOTES 1. 2. Assembly packaged in plastic bag and tag identified with manufacturer's name and part number. Glenair 180-071 Connector features: A. Plug Body: Aluminum Alloy (See Table II). B. O-Ring: Fluorosilicone. C. Fiber Optic Termini: Glenair 181 Series (Not supplied). D. Operating Temperature Range: -55°C to +125°C. Metric dimensions (mm) are in parentheses. 3. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-26 Environment Resistant for Glenair 181-001 and 181-002 Termini 180-071 (-6) Plug Single Channel Fiber Optic Plug Connector A° B° D° C° As Viewed from Front of Connector TABLE I: KEY LOCATION Pos 1 2 3 4 5 A° 95 80 95 80 95 B° 141 141 141 141 141 C° 208 208 223 223 208 D° 300 300 300 300 275 TABLE II: FINISH SYM C M NF ZN Z1 MATERIAL Aluminum Aluminum Aluminum Aluminum Stainless Steel FINISH Black Anodize Electroless Nickel Cadmium, Olive Drab over Electroless Nickel Zinc-Nickel, Olive Drab over Electroless Nickel Passivate © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-27 MIL-DTL-38999 Connectors
