180-071-Z145

180-071 (-4) Jam Nut Single Channel Fiber Optic Receptacle Connector Environment Resistant for Glenair 181-001 and 181-002 Termini MIL-DTL-38999 Connectors Polarizing Master Keyway 180-071-C 4 1 Product Series Basic Number Finish (Table II) 4 = Jam Nut Receptacle Assembly Alternate Key Position (1,2,3,4, & 5) (Table I) 1.250 (31.8) Max Interfacial Seal .375-.05p-.1L-DS-2A .125 (3.2) Max Panel Thickness O-Ring .375-24 UNF-2A -4 JAM NUT MTG. RECEPT. ASSY. O.783 (19.9) O .510 (13.0) .505 (12.8) .461 (11.7) .457 (11.6) RECOMMENDED PANEL CUTOUT APPLICATION NOTES 1. 2. Assembly packaged in plastic bag and tag identified with manufacturer's name and part number. Glenair 180-071 Connector features: A. Receptacle Body, Jam Nut Coupling Nut: Aluminum Alloy (See Table II). B. O-Ring, Interfacial Seal: Fluorosilicone. C. Fiber Optic Termini: Glenair 181 Series (Not supplied). D. Operating Temperature Range: -55°C to +125°C. Metric dimensions (mm) are in parentheses. 3. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-28 180-071 (-4) Jam Nut Single Channel Fiber Optic Receptacle Connector Environment Resistant for Glenair 181-001 and 181-002 Termini A° B° D° C° As Viewed from Rear of Connector TABLE I: KEYWAY LOCATION Pos 1 2 3 4 5 A° 95 80 95 80 95 B° 141 141 141 141 141 C° 208 208 223 223 208 D° 300 300 300 300 275 TABLE II: FINISH SYM C M NF ZN Z1 MATERIAL Aluminum Aluminum Aluminum Aluminum Stainless Steel FINISH Black Anodize Electroless Nickel Cadmium, Olive Drab over Electroless Nickel Zinc-Nickel, Olive Drab over Electroless Nickel Passivate © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-29 MIL-DTL-38999 Connectors
