181-001-533

MIL-DTL-38999 Connectors o .113 (2.9) Protective Cover Alignment Sleeve A Dia .062 (1.6) Dia .116 (3.0) .114 (2.9) Dia .110 (2.8) .092 (2.3) 181-001 Size 16 Fiber Optic Socket Terminus MIL-PRF-29504/5 181-001-126 K Product Series Basic Number Dash Number (Table I) K = Stainless Steel Alignment Sleeve (Omit for Ceramic Alignment Sleeve) .346 (8.8) .246 (6.7) o .082 (2.1) PROTECTIVE COVER ALIGNMENT SLEEVE (Included with Terminus) 1.132 (28.8) 1.025 (26.0) .537 (13.6) o .130 Max .069 (1.8) Dia Shrink Tube .500 (12.7) .080 (2.0) Max Dia. Cable Bottoming Surface See Note 5 APPLICATION NOTES 1. Assembly packaged in plactic bag and tag identified with manufacturer’s name and part number. 2. Material/ Finish: Ferrule, Alignment Sleeve: Zirconia Ceramic/N.A. or Stainless Steel/Passivate. Terminus Assembly: Stainless Steel/Passivate Spacer, Spring, and cover: Stainless Steel/Passivate Shrink Tube: Kynar/N.A 3. Alignment Sleeve & Protective Cover can also be ordered separately (Table II). 4. Metric dimensions (mm) are indicated in parentheses. 5. Threaded protective cover must be retained using Thread locker “Loctite 222” prior to insertion and fully seated against Terminus body as shown. See Assembly Procedure on page B-8 for complete termination instruction. 6. See 182-001S for Socket Terminus Polishing Tool. 7. Recommended insertion/removal tool: P/N: M81969/14-03 or equivalent 8. Consult factory for qualification status. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-2 181-001 Size 16 Fiber Optic Socket Terminus MIL-PRF-29504/5 TABLE I: FIBER SIZE Assembly Dash Number 181-001-125 181-001-126S 181-001-126 181-001-127 181-001-142 181-001-144 181-001-145 181-001-156 181-001-157 181-001-173 181-001-175 181-001-231 181-001-236 181-001-286 181-001-448 181-001-533 Fiber Size Core/Cladding** 9/125 (Singlemode) 9/125 (Singlemode) 50/125 & 62.5/125 50/125 & 62.5/125 100/140 100/140 100/140 62.5/125/155 (Polyimide) 62.5/125/155 (Polyimide) 100/140/172 (Polyimide) 100/140/172 (Polyimide) 200/230 200/233 200/280 400/440 486/500 A Dia. (Microns) 125.5 126 126 127 142 144 145 156 157 173 175 231 236 286 448 533 Reference Only M29504/5-XXXX M29504/5-4237* M29504/5-4238* M29504/5-4239* M29504/5-4046 M29504/5-4049 M29504/5-4050 N/A M29504/5-4240* M29504/5-4241* M29504/5-4088 M29504/5-4242* N/A M29504/5-4243* M29504/5-4244* M29504/5-4245* N/A * See Note 8 ** Consult factory for termini which accomodate 600 micron and 1000 micron plastic or glass fiber. TABLE II: TERMINUS ACCESSORIES Assembly Dash Number 181-001-S 181-001-K 181-001-C Terminus Accessories Ceramic Alignment Sleeve Stainless Steel Alignment Sleeve Protective cover © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-3 MIL-DTL-38999 Connectors
