181-002-145

MIL-DTL-38999 Connectors Product Series Basic Number Dash Number (Table I) .299 (7.6) / .295 (7.5) .062 (1.6) Dia .270 (6.9) / .262 (6.7) A Dia o .130 Max © 2006 Glenair, Inc. www.glenair.com 181-002 Size 16 Fiber Optic Pin Terminus MIL-PRF-29504/4 181-002-126 .783 (19.9) .033 (0.8) / .029 (0.7) .069 (1.8) Dia Shrink Tube .500 (12.7) .080 (2.0) Max Dia Cable APPLICATION NOTES 1. Assembly packaged in plactic bag and tag identified with manufacturer’s name and part number. 2. Material/ Finish: Ferrule, Alignment Sleeve: Zirconia Ceramic/N.A. or Stainless Steel/Passivate. Terminus Assembly: Stainless Steel/Passivate Shrink Tube: Kynar/N.A 3. See 182-001P for Pin terminus Polishing Tool. 4. Metric dimensions (mm) are indicated in parentheses. 5. Recommended insertion/removal tool: P/N: M81969/14-03 or equivalent 6. Consult factory for qualification status. 7. See Glenair Assembly Procedure on page B-8 for complete termination instructions. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-4 181-002 Size 16 Fiber Optic Pin Terminus MIL-PRF-29504/4 TABLE I: FIBER SIZE Assembly Dash Number 181-002-125 181-002-126S 181-002-126 181-002-127 181-002-142 181-002-144 181-002-145 181-002-156 181-002-157 181-002-173 181-002-175 181-002-231 181-002-236 181-002-286 181-002-448 181-002-533 Fiber Size Core/Cladding** 9/125 (Singlemode) 9/125 (Singlemode) 50/125 & 62.5/125 50/125 & 62.5/125 100/140 100/140 100/140 62.5/125/155 (Polyimide) 62.5/125/155 (Polyimide) 100/140/172 (Polyimide) 100/140/172 (Polyimide) 200/230 200/233 200/280 400/440 486/500 A Dia. (Microns) 125.5 126 126 127 142 144 145 156 157 173 175 231 236 286 448 533 Reference Only M29504/4-XXXX M29504/4-4208* M29504/4-4209* M29504/4-4210* M29504/4-4040 M29504/4-4043 M29504/4-4044 N/A M29504/4-4211* M29504/4-4212* M29504/4-4087 M29504/4-4213* N/A M29504/4-4214* M29504/4-4215* M29504/4-4216* N/A * See Note 6 ** Consult factory for termini which accomodate 600 micron and 1000 micron plastic or glass fiber. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-5 MIL-DTL-38999 Connectors
