181-011-233

Size 16 Front Release with Protective Cover Alignment Sleeve 181-011 Fiber Optic Socket Terminus Custom Connector System A Dia .115 (3.0) Dia Spring Clip .16 (4.1) Protective Cover With Alignment Sleeve (See Note 3) 181-011-126 Product Series Basic Number Dash Number (Table I) .85 (21.6) .71 (18.0) O-ring .077 (2.0) .116 Dia (3.0) Dia Crimp Sleeve P/n 265-002 (See Note 3) APPLICATION NOTES 1. 2. Assembly packaged in plastic bag and tag identified with manufacturer's name and part number. Material/Finish: Ferrule: Zirconia Ceramic/N.A. Protective Cover: Spring Alloy Terminus Assembly: Stainless Steel/Passivate Spring Material: Stainless Steel Passivate Spring Clip: Spring Alloy O-Ring: Fluorosilicone Crimp Sleeve: Brass Alloy/Nickel 3. 4. 5. Alignment Sleeve with Protective Cover and Crimp Sleeve may be ordered separately (Table II). Consult factory for termination and assembly tools/procedures. Metric dimensions (mm) are in parentheses. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-2 Size 16 Front Release with Protective Cover Alignment Sleeve TABLE I: DASH NUMBER Assembly Dash No. 125 126 126 142 156 175 233 236 280 440 Fiber Size Core/Cladding 9/125 (Singlemode) 50/125 62.5/125 100/140 62.5/125/155 (Polyimide) 100/140/172 (Polyimide) 200/225 200/230 200/280 400/440 A Dia (mm) .125 .126 .126 .142 .156 .175 .233 .236 .286 .448 TABLE II: TERMINUS ACCESSORIES Assembly Dash No. 181-011-S 181-011-K 182-005S 265-002 182-015 182-016 182-014 182-013 182-012 Terminus Accessories Protective Cover with Ceramic Alignment Sleeve Protective Cover with Stainless Steel Alignment Sleeve Socket Terminus Polishing Tool Crimp Sleeve Removal Tool Alignment Sleeve Insertion/ Removal Tool Insertion Tool, 90° Insertion Tool, Straight Crimp Tool © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-3 Custom Connector System 181-011 Fiber Optic Socket Terminus
