181-040-1250C

MIL-PRF-28876 Connectors Product Series Basic Number Dash Number (Table I) .118 (3.0) .114 (2.9) Dia .080 (2.0) .074 (1.9) Dia 181-040 M29504/15 Style Front Release Socket Terminus Size 16 181-040-1260 C N N = Alignment Sleeve Assembly Not required (Omit to receive Alignment Sleeve) Crimp Sleeve Designator Omit if None (See Table II) .955 (24.3) Max .800 (20.3) Max Retaining Clip .277 (7.0) .267 (6.8) (See Note 6) Alignment Sleeve Terminus Assembly .158 (4.0) Max .158 (4.0) Min A Dia Ferrule Hole .118 (3.0) .115 (2.9) Dia Crimp Sleeve (See Note 3) Environmental Seal Ferrule Protective Cover TABLE I: DASH NUMBER Assembly Dash Number 1250 1255 1260 1270 1420 A Dia (Microns) 126.0 125.0 126.5 125.5 127.0 126.0 128.0 127.0 143.0 142.0 TABLE II: CRIMP SLEEVE DESIGNATOR Designator C Cable Diameter 2.0-2.4 mm (MIL-Spec) Part Number 265-008 TABLE III: TERMINUS ACCESSORIES Part Number 265-010 182-012 182-013 182-014 182-015 182-016 182-017 Accessory Alignment Sleeve Assembly Crimp Tool Insertion Tool, Straight Insertion Tool, 90° Removal Tool Alignment Sleeve Assembly Insertion/Removal Tool Hand Polishing Tool Consult Factory for Additional Sizes APPLICATION NOTES 1. 2. Assembly packaged in plastic bag and tag identified with manufacturer’s name and part number Material/ Finish: Alignment Sleeve, Ferrule: Zirconia Ceramic/ N.A. Protective cover: Spring Alloy / Nickel Terminus Assembly: Stainless Steel / Passivate Retaining Clip: Spring Alloy / N.A. Seal: Fluorosilicone 3. 4. 5. 6. Crimp Sleeve: Brass Alloy / Nickel Alignment Sleeve Assembly and Crimp Sleeve may be ordered separately (Tables II and III) Metric dimensions (mm) are in parentheses. Dummy Terminus: Part Number 181-051 Dimension to be measured when installed into insert equivalent fixture per MIL-PRF-29504/15 © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-2
