181-050-1270C

for Use with M83526/16/17 Style Hermaphroditic Connectors 181-050-1260 C Product Series Basic Number Dash Number (Table I) Add “C” to include Crimp Sleeve (Omit for None) TABLE I: DASH NUMBER Assembly Dash No. 181-050-1250 181-050-1255 181-050-1260 181-050-1270 181-050-1420 181-050-2300 A Dia (mm) Max Min .1260 .1265 .1270 .1280 .1430 .2340 .1250 .1255 .1260 .1270 .1420 .2300 Fiber Type (Typical) SM SM SM & MM MM MM MM SM = Singlemode MM = Multimode 1.275 (32.4) Max 1.043 (26.49)Max 1.034 (26.3) Min .253 (6.4) Max .246 (6.2) Min Sealing Feature A Dia 2.5 mm Dia Ferrule Ferrule Housing Spring Retaining Ring Sleeve APPLICATION NOTES 1. Assembly packaged in plastic bag and tag identified with manufacturer’s name and part number. 2. Material/ Finish: Ferrule: Zirconia Ceramic/ N.A. Terminus Assembly: Stainless Steel/ Passivate Spring: High Tensile Stainless Steel/ Passivate Sliding Sleeve: Stainless Steel/ Passivate Retaining Ring: Stainless Steel/ Passivate 3. Insertion/Removal Tool: Consult factory 4. Consult factory for assembly and termination tools. 5. For Glenair GFOCA connector product, refer to Glenair 180-116 and 180-117 drawings (Pages F-4 and F-6). 6. Metric dimensions (mm) are indicated in parentheses. 7. Crimp sleeve: See 265-008. © 2006 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com F-3 GFOCA Connectors 181-050 M29504/16 Style GFOCA Genderless Terminus
