220-01H22

Geo-Marine® Connectors 220-01 and 220-11 Connector Receptacle Assembly In-Line B Thread Master Key Master Key Indicator Piston O-Ring 220-01: 1.19 (30.2) Max 220-11: 1.44 (36.6) Max Direction of Pressure Capability - Class H C A Thread 220-01 H 24-61 P N Series No. Shell Style 01 = Standard 11 = Scoop Proof Class H = Hermetic E = Environmental Polarization (N, 1, 2, 3, 4) P = Pins S = Sockets (Class E only) Insert Arrangement Shell Size Prior to use, lubricate O-rings with high grade silicone lubricant (Moly-kote M55 or equivalent). Metric dimensions (mm) are indicated in parentheses. SHELL SIZE 10 12 14 16 18 20 22 24 DIMENSIONS A THREAD B THREAD CLASS 2A CLASS 2A 5/8 - 24 UNEF .750 - .1P - .1L 3/4 - 20 UNEF .875 - .1P - .1L 7/8 - 20 UNEF 1.000 - .1P - .1L 1 - 20 UNEF 1.125 - .1P - .1L 1 1/8 - 16 UN 1.250 - .1P - .1L 1 1/4 - 16 UN 1.375 - .1P - .1L 1 3/8 - 16 UN 1.500 - .1P - .1L 1 1/2 - 16 UN 1.625 - .1P - .1L REPLACEMENT O-RING PART NUMBERS * C DIA MAX .906 (23.0) 1.031 (26.2) 1.156 (29.4) 1.281 (32.5) 1.531 (38.9) 1.656 (42.1) 1.781 (45.2) 1.906 (48.4) PISTON SHELL O-RING SIZE 2-014 10 2-016 12 2-018 14 2-020 16 2-022 18 20 2-024 22 2-026 24 2-028 * Parker O-ring part numbers. Compound N674-70 or equivalent. © 2003 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com 10
