220-03H10_09

Series 22 Geo-Marine Master Key Indicator - Red Slot Shell Style 03 = Standard 13 = Scoop Proof Shell Size Solder Mount Bulkhead Connector Receptacle 220-03 and 220-13 Series 22 Geo-Marine® B Thread Piston O-Ring 220-03: 1.19 (30.2) Max 220-13: 1.44 (36.6) Max Direction of Pressure Capability - Class H D C Recommended Panel Cutout .06 (1.5) .06 (1.5) .65 (16.5) Max E Contacts P = Pins 220 - 03 Series No. H Class 24 - 61 Insert Arrangement P N Polarization N, 1, 2, 3, 4 Prior to use, lubricate O-rings with high grade silicone lubricant (Moly-kote M55 or equivalent). Metric dimensions (mm) are indicated in parentheses. H = Hermetic DIMENSIONS G SHELL SIZE 10 12 14 16 18 20 22 24 B THREAD CLASS 2A .750 - .1P - .1L .875 - .1P - .1L 1.000 - .1P - .1L 1.125 - .1P - .1L 1.250 - .1P - .1L 1.375 - .1P - .1L 1.500 - .1P - .1L 1.625 - .1P - .1L C DIA MAX .870 (22.1) .995 (25.3) 1.120 (28.4) 1.245 (31.6) 1.370 (34.8) 1.495 (38.0) 1.620 (41.1) 1.745 (44.3) D DIA 1.00 (25.4) 1.13 (28.7) 1.25 (31.8) 1.38 (35.1) 1.50 (38.1) 1.63 (41.4) 1.75 (44.5) 1.88 (47.8) E DIA +.010 +(0.3) -.000 -(0.0) .875 (22.2) 1.000 (25.4) 1.125 (28.6) 1.250 (31.8) 1.375 (34.9) 1.500 (38.1) 1.625 (41.3) 1.750 (44.5) REPLACEMENT O-RING PART NUMBERS * SHELL PISTON SIZE O-RING 10 2-014 12 2-016 14 2-018 16 2-020 18 2-022 20 2-024 22 2-026 24 2-028 * Parker O-ring part numbers. Compound N674-70 or equivalent. © 2009 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com G-8 G-8
