220-07H10_09

Series 22 Geo-Marine JAM NUT E Master Key Shell Style 07 = Standard 17 = Scoop Proof Shell Size Rear Mounted Jam Nut Box Mount Receptacle 220-07: 1.32 (33.5) Max 220-17: 1.57 (39.9) Max .18 (4.8) Recommended Panel Cutout 220-07 and 220-17 Series 22 Geo-Marine® Flange O-Ring B Thread Master Key Indicator Red Dot Piston O-Ring (See Note 1) Direction of Pressure Capability - Class H C Thread .16 (4.1) Ref .50 (12.7) Max Panel Accomodation D Ø .021 G .018 .125 Typ F .050 Typ Contacts P = Pins 220 - 07 Series No. H Class 24 - 61 Insert Arrangement P N Polarization N, 1, 2, 3, 4 Prior to use, lubricate O-rings with high grade silicone lubricant (Moly-kote M55 or equivalent). Metric dimensions (mm) are indicated in parentheses. H = Hermetic DIMENSIONS SHELL SIZE 10 12 14 16 18 20 22 24 B THREAD CLASS 2A .750 - .1P - .1L .875 - .1P - .1L 1.000 - .1P - .1L 1.125 - .1P - .1L 1.250 - .1P - .1L 1.375 - .1P - .1L 1.500 - .1P - .1L 1.625 - .1P - .1L C THREAD CLASS 2A 7/8 - 20 UNEF 1 - 20 UNEF 1 1/8 - 16 UN 1 1/4 - 16 UN 1 3/8 - 16 UN 1 1/2 - 16 UN 1 5/8 - 16 UN 1 3/4 - 16 UN D DIA 1.25 (31.8) 1.38 (35.1) 1.50 (38.1) 1.63 (41.4) 1.75 (44.5) 1.88 (47.8) 2.00 (50.8) 2.12 (53.8) E FLATS 1.125 (28.6) 1.250 (31.8) 1.500 (38.1) 1.625 (41.3) 1.750 (44.5) 1.875 (47.6) 2.000 (50.8) 2.125 (54.0) F DIA ±.005 ±(0.1) .885 (22.5) 1.010 (25.7) 1.135 (28.8) 1.260 (32.0) 1.385 (35.2) 1.510 (38.4) 1.635 (41.5) 1.760 (44.7) ±.005 .835 .960 1.085 1.210 1.335 1.460 1.585 1.710 G ±(0.1) (21.2) (24.4) (27.6) (30.7) (33.9) (37.1) (40.3) (43.4) G RECOMMENDED JAM NUT INSTALLATION TORQUE vALUES SHELL TORQUE ± 5% SIZE INCH-POUNDS NEWTON-METERS 10 95 10.73 12 110 12.43 14 140 15.82 16 170 19.21 18 195 22.03 20 215 24.29 22 235 26.55 24 260 29.38 NOTE 1: Flat and master key indicator rotates with master key per position noted on introductory pages. © 2009 Glenair, Inc. www.glenair.com CAGE Code 06324 REPLACEMENT O-RING PART NUMBERS * SHELL PISTON FLANGE SIZE O-RING O-RING 10 2-014 2-021 12 2-016 2-023 14 2-018 2-025 16 2-020 2-027 18 2-022 2-029 20 2-024 2-030 22 2-026 2-031 24 2-028 2-032 * Parker O-ring part numbers. Compound N674-70 or equivalent. Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com G-10 G-10
