220-12E12

220-02 and 220-12 Connector Receptacle Assembly Square Flange Mount 220-02: 1.19 (30.2) Max 220-12: 1.44 (36.6) Max .400 (10.2) Ref. F Piston O-ring Direction of Pressure Capability - Class H Master Key Master Key Indicator Flange O-ring A Thread Recommended Panel Cutout D Typ C Typ D Typ B Thread 220-02 H 24-61 P N Series No. Shell Style 02 = Standard 12 = Scoop Proof Class H = Hermetic E = Environmental Polarization (N, 1, 2, 3, 4) P = Pins S = Sockets (Class E only) Insert Arrangement Shell Size DIMENSIONS SHELL SIZE 10 12 14 16 18 20 22 24 A THREAD CLASS 2A 5/8 - 24 UNEF 3/4 - 20 UNEF 7/8 - 20 UNEF 1 - 20 UNEF 1 1/8 - 16 UN 1 1/4 - 16 UN 1 3/8 - 16 UN 1 1/2 - 16 UN B THREAD CLASS 2A .750 - .1P - .1L .875 - .1P - .1L 1.000 - .1P - .1L 1.125 - .1P - .1L 1.250 - .1P - .1L 1.375 - .1P - .1L 1.500 - .1P - .1L 1.625 - .1P - .1L C DIM 1.188 (30.2) 1.312 (33.3) 1.438 (36.5) 1.562 (39.7) 1.750 (44.5) 1.875 (47.6) 2.000 (50.8) 2.125 (54.0) D DIM .938 (23.8) 1.062 (27.0) 1.188 (30.2) 1.250 (31.8) 1.375 (34.9) 1.500 (38.1) 1.625 (41.3) 1.750 (44.5) .12 (3.1) Ref. Tapped mounting hole - Typical (not to break through to dry side of panel). E Prior to use, lubricate O-rings with high grade silicone lubricant (Moly-kote M55 or equivalent). Metric dimensions (mm) are indicated in parentheses. E DIA +.015 +(0.4) -.000 -(0.0) .844 (21.4) .969 (24.6) 1.078 (27.4) 1.219 (31.0) 1.359 (34.5) 1.515 (38.5) 1.640 (41.7) 1.765 (44.8) MOUNTING/HARDWARE INFORMATION SHELL F MTG SCREW SIZE DIA REF. 10 .125 (3.2) No. 4 12 .125 (3.2) No. 4 14 .125 (3.2) No. 4 16 .125 (3.2) No. 4 18 .125 (3.2) No. 4 20 .125 (3.2) No. 4 22 .125 (3.2) No. 4 24 .156 (4.0) No. 6 REPLACEMENT O-RING PART NUMBERS * SHELL PISTON FLANGE SIZE O-RING O-RING 10 2-014 2-021 12 2-016 2-023 14 2-018 2-025 16 2-020 2-027 18 2-022 2-029 20 2-024 2-030 22 2-026 2-031 24 2-028 2-032 * Parker o-ring part numbers. Compound N674-70 or equivalent. Printed in U.S.A. © 2003 Glenair, Inc. CAGE Code 06324 GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com 11 Geo-Marine® Connectors
