230-018

Bayonet Coupling Solder Flange Mount Receptacle MS3443 Type Connector Style 018 = Solder Flange Mount Hermetic Receptacle Alternate Insert Arrangement W, X, Y or Z (Omit for Normal) 230-018 MIL-DTL-26482 Series II Type Hermetic MIL-DTL 26482 Type Insert Arrangement Per MIL-STD-1669 230 - 018 Series 230 MIL-DTL-26482 Type FT 10 - 6 Shell Size P X Material/Finish Z1 = Stainless Steel/ Passivated ZL = Stainless Steel/ Nickel Plated FT = C1215 Stainless Steel/Tin Plated (See Note 2) Contact Type P = Solder Cup, Pin Face X = Eyelet, Pin Face D Master Polarizing Keyway .060 Width Polarizing Stripe L Max Ref F Peripheral Gasket A .047 .028 t Vitreous Inser " Contact Style "P C Contact Style "X" B C F E D Interfacial Seal Painted Bayonet Pin Ends D Min ØA P (Size 20 Contacts) V (Size 16 & 12 Contacts) J APPLICATION NOTES 1. 2. To be identified with manufacturer’s name, part number and date code, space permitting. Material/Finish: Shell: Z1 - 304L stainless steel/passivate. FT - C1215 stainless steel/tin plated. Titanium and Inconel® available. Consult factory. Contacts - 52 Nickel alloy/gold plate. Bayonets - Stainless steel/passivate. Seals - Silicone elastomer/N.A. Insulation - Glass/N.A. Consult factory and/or MIL-STD-1669 for arrangement and insert position options. 4. Glenair 230-018 will mate with any QPL MIL-DTL-26482 Series II bayonet coupling plug of same size and insert polarization. Performance: Hermeticity -
