Bayonet Coupling Solder Mount Receptacle with Crimp Removable Contacts • MS3473 Type Alternate Insert Arrangement W, X, Y or Z (Omit for Normal) (See Table II) 230-020 MIL-DTL-26482 Series II Type Hermetic MIL-DTL 26482 Type Connector Style 020 = Hermetic Solder Mount Receptacle with Solderless Contacts Insert Arrangement Per MIL-STD-1669 230 - 020 Series 230 MIL-DTL-26482 Type FT 10 - 6 Shell Size D X Material/Finish Z1 = Stainless Steel/ Passivated ZL = Stainless Steel/ Nickel Plated FT = C1215 Stainless Steel/Tin Plated (See Note 2) Contact Type D = Pin Face, Crimp Rear, Removable Sockets (See Note 6) ØK D L Max .047 .026 Master Polarizing Keyway .060 Width Polarizing Stripe F Peripheral Gasket Vitreous Insert PANEL CUT-OUT Rear Insulator Assembly A F E D B C C Interfacial Seal Painted Bayonet Pin Ends ØA .070 ±.031 Wide Blue Color Band Located Within .125 Of Flange © 2009 Glenair, Inc. www.glenair.com CAGE CODE 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 D-22 Bayonet Coupling Solder Mount Receptacle with Crimp Removable Contacts • MS3473 Type HERMETIC LEAK RATE MOD CODES Designator –585A –585B –585C Required Leak Rate 1 x 10-10 cc’s Helium per second 1 x 10-9 cc’s Helium per second 1 x 10-8 cc’s Helium per second TABLE I: CONNECTOR AND CUT-OUT DIMENSIONS Shell Size 8 10 12 14 16 18 20 22 24 A Dia Ø.010 (0.3) .625 (15.9) .750 (19.1) .844 (21.4) .969 (24.6) 1.094 (27.8) 1.218 (30.9) 1.312 (33.3) 1.438 (36.5) 1.564 (39.7) C Dia .563/.557 (14.3/14.1) .673/.667 (17.1/16.9) .782/.776 (20.0/19.7) .907/.901 (23.0/22.9) 1.032/1.026 (26.2/26.1) 1.157/1.151 (29.4/29.2) 1.251/1.245 (31.8/31.6) 1.376/1.371 (35.0/34.8) 1.501/1.495 (38.1/38.0) F .735/.711 (18.7/18.1) .735/.711 (18.7/18.1) .735/.711 (18.7/18.1) .735/.711 (18.7/18.1) .735/.711 (18.7/18.1) .735/.711 (18.7/18.1) .823/.799 (20.9/20.3) .823/.799 (20.9/20.3) .823/.799 (20.9/20.3) K .570 (14.5) .680 (17.3) .789 (20.0) .914 (23.2) 1.039 (26.4) 1.164 (29.6) 1.258 (32.0) 1.383 (35.1) 1.508 (38.3) L Max 1.078 (27.4) 1.078 (27.4) 1.078 (27.4) 1.078 (27.4) 1.078 (27.4) 1.078 (27.4) 1.140 (29.0) 1.140 (29.0) 1.140 (29.0) APPLICATION NOTES 1. 2. To be identified with manufacturer’s name, part number and date code, space permitting. Material/Finish: Shell: Z1 - 304L stainless steel/passivate. FT - C1215 stainless steel/tin plated. Titanium and Inconel® available. Consult factory. Contacts - 52 Nickel alloy/gold plate. Bayonets - Stainless steel/passivate. Seals - Silicone elastomer/N.A. Insulation - Glass/N.A. Rear insulator - Rigid dielectric/N.A. Glenair 230-020 will mate with any QPL MIL-DTL-26482 4. Series II bayonet coupling plug of same size and insert polarization. Performance: Hermeticity -
