230-022

Bayonet Coupling Jam Nut Mount Receptacle with Crimp Removable Contacts • MS3479 Type Alternate Insert Arrangement W, X, Y or Z (Omit for Normal) (See Table II) 230-022 MIL-DTL-26482 Series II Type Hermetic MIL-DTL 26482 Type Connector Style 022 = Jam-Nut Mount Receptacle with Solderless Contacts Insert Arrangement Per MIL-STD-1669 230 - 022 Series 230 MIL-DTL-26482 Type FT 10 - 6 Shell Size D X Material/Finish Z1 = Stainless Steel/ Passivated FT = C1215 Stainless Steel/Tin Plated (See Note 2) Contact Type D = Pin Face, Crimp Rear, Removable Sockets (See Note 6) L F D A Master Polarizing Keyway .060 Width Polarizing Stripe ØB Peripheral Gasket Interfacial Seal Vitreous Insert G R O-ring Rear Insulator Assembly A F E D B C C A Painted Bayonet Pin Ends J S .027 .011 V Thread .070 ±.031 Wide Blue Color Band Located App. As Shown APPLICATION NOTES 1. 2. To be identified with manufacturer’s name, part number and date code, space permitting. Material/Finish: Shell: Z1 - 304L stainless steel/passivate. FT - C1215 stainless steel/tin plated. Series II bayonet coupling plug of same size and insert polarization. 4. Performance: Hermeticity -
