230-023

Bayonet Coupling Square Flange Receptacle Connector with Solder Terminals Alternate Insert Arrangement W, X, Y, or Z (Omit for Normal) 230-023 MIL-DTL-83723/79 Series III Type Hermetic MIL-DTL 83723 Series 230 MIL-DTL-83723 Type Connector Style 023 = Hermetic Square Flange Mount Receptacle Insert Arrangement Per MIL-STD-1554 230 - 023 FT 12 - 3 Shell Size P Contact Type P = Solder Cup X Material Designation FT = Carbon Steel/ Tin Plated Z1 = Stainless Steel/ Passivated .400 Max (Contact Size 16 & 12) .330 Max (Contact Size 20) .072/.052 ØH .108/.078 ØD Shell I.D. E 1 1 A (Typ) B (Typ) 2 3 ØC Max ØF ØG Max 3 2 Ø Cc (Min I.D.) .890 Max Ø E Max Resilient Insert Painted Bayonet Pin Ends APPLICATION NOTES 1. 2. To be identified with manufacturer’s name, part number and date code, space permitting. Material/Finish: Shell*: Z1 - Stainless steel/passivated. FT - Carbon steel/tin plated. Contacts - 52 Nickel alloy/gold plated. Bayonets - Stainless steel/passivated. Seals - Silicone elastomer/N.A. Insulation - Glass/N.A. Glenair 230-023 will mate with any QPL MIL-DTL-83723/75 & 77 Series III bayonet coupling plug of same size, keyway, and insert polarization. * Additional shell materials available, including titanium and Inconel®. Consult factory for ordering information. © 2009 Glenair, Inc. www.glenair.com CAGE CODE 06324 Printed in U.S.A. E-Mail: sales@glenair.com 4. Performance: Hermeticity -
