230-030

Threaded Coupling Solder Flange Mount Receptacle with Solder Cup Terminations Connector Style 030 = Hermetic Solder Flange Mount Receptacle Alternate Insert Arrangement W, X, Y, or Z (Omit for Normal) 230-030 MIL-DTL-83723/89 Series III Type Hermetic MIL-DTL 83723 Shell Size Insert Arrangement Per MIL-STD-1554 230 - 030 Series 230 MIL-DTL-83723 Type FT 12 - 3 P Contact Type P = Solder Cup X Material Designation FT = Carbon Steel/Tin Plated Z1 = Stainless Steel/Passivated ZL = Stainless Steel/Nickel Plated .224/.164 Contact Sizes 12 & 16 .194/.134 Contact Size 20 .031 .016 .062 .047 ØD Shell I.D. E ØA 1 2 3 ØC Max ØF Max Seal 1 ØG Max 3 2 ØK (Min I.D.) .109 .079 .795 .775 (.904 Max) Ø E Max Resilient Insert APPLICATION NOTES 1. 2. To be identified with manufacturer’s name, part number and date code, space permitting. Material/Finish: Shell* and Jam-Nut: Z1 - Stainless steel/passivated. FT - Carbon steel/tin plated. ZL - Stainless steel/nickel plated. Contacts - 52 Nickel alloy/gold plated. Bayonets - Stainless steel/passivated. Seals - Silicone elastomer/N.A. Insulation - Glass/N.A. Glenair 230-030 will mate with any QPL MIL-DTL-83723/86, /91, /95 and /97 Series III threaded coupling plug of same * Additional shell materials available, including titanium and Inconel®. Consult factory for ordering information. © 2009 Glenair, Inc. www.glenair.com CAGE CODE 06324 Printed in U.S.A. E-Mail: sales@glenair.com size, keyway, and insert polarization. 4. Performance: Hermeticity
