Bulkhead Feed-Thrus
Connector Series 232 - D38999 Series II Type Shell Style 00 - Wall Mount Connector Type 104 - Env. Bulkhead Feed-Thru SHELL SIZE 08 10 A MAX .474(12.0) .591(15.0) .751(19.1) .876(22.3) 1.001(25.4) 1.126(28.6) 1.251(31.8) 1.376(35.0) 1.501(38.1) B SQ .594(15.1) .719(18.3) .812(20.6) .906(23.0) .969(24.6) 1.062(27.0) 1.156(29.4) 1.250(31.8) 1.375(34.9)
232-104-00 Wall Mount Environmental Bulkhead Feed-Thru
MIL-DTL-38999 Series II Type
Shell Size 08 10 12 14 16 18 20 22 24
1.25 Max
Insert Arrangement Per MIL-DTL-38999 Series II MIL-STD-1560 Alternate Key Position A, B, C, D (N = Normal)
.602 Ref
Panel Accom.
Flange Side Ref
A TYP
232 - 104 - 00 M 10 - 35
P N - 01
Panel Accomodation 01 - .0625″ (Min) .125″ (Max) 02 - .0625″ (Min) .250″ (Max) 03 - .0625″ (Min) .500″ (Max)
.156 Max
Connector Material and Finish M - Aluminum / Electroless Nickel NC - Aluminum / Zinc-Cobalt NF - Cad / O.D. Over Electroless Nickel (1000hr Salt Spray) ZN - Aluminum Zinc-Nickel Olive Drab MT - Aluminum / Ni-PTFE 1000 Hour GreyTM AL - Aluminum / Pure Electrodeposited Aluminum
Contact Termination P - Pin on Flange Side S - Socket on Flange Side
B TYP
TABLE I: CONNECTOR DIMENSIONS
C SQ .818(20.8) .944(24.0) 1.037(26.3) 1.131(28.7) 1.224(31.1) 1.318(33.5) 1.443(36.7) 1.568(39.8) 1.693(43.0) D DIA .125(3.2) .125(3.2) .125(3.2) .125(3.2) .125(3.2) .125(3.2) .125(3.2) .125(3.2) .156(4.0) E ±.005(0.1) .580(14.7) .697(17.7) .885(22.5) 1.010(25.7) 1.135(28.8) 1.260(32.0) 1.385(35.2) 1.510(38.4) 1.635(41.5)
C
E
12 14 16 18 20 22 24
Insert Arrangement per MIL-DTL-38999, Series lI MIL-STD-1560
B Ref
APPLICATION NOTES
1. Material/Finish: Shells and nuts – Al alloy,6061-T6,QQ-A-225/8, see Table II Contacts – Leaded nickel copper - gold plate MIL-G-45204, Type II, Class I. Bayonet pins – AISI 300 series stainless steel/passivate, QQ-P-35 Hoods – AISI 305 series stainless steel/passivate, QQ-P -35. Inserts –High grade rigid dielectric/N.A. Seals – Silicone/ N.A. Metric Dimensions (mm) are indicated in parentheses.
D DIA (4 Places) E Dia Recommended Panel Cut-Out
2.
© 2008 Glenair, Inc. www.glenair.com
CAGE CODE 06324
Printed in U.S.A. E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
E-8
