233-101-G6 Type 4 Lanyard Release Plug for MIL-STD-1760
and Other MIL-DTL-38999 Series III Type Hybrid Signal, Power, Coax and Twinax Arrangements
Environmental Connectors
Product Series Basic Number EMI Plug
Insert Arrangement 25-20 Per MIL-STD-1560
Lanyard Length Code See Table III Alternate Key Position A, B, C, D or E (N for Normal)
Finish Table II
Shell Size Table I
233 - 101 - G6
M
25 - 20
P S
P
Contact Style
-
A
Pin Socket
E
D
L Grounding Spring .061-.071 ø Wire, 7X7 Construction, CRES, .093 OD Nylon Jacket Medium Diamond Knurl (optional) Blue Color Band Insert Arrangement 25-20 per MIL-STD-1560. Mating face of pin insert is shown. Socket face is opposite.
1
1
R P
A S B C Z Y 4 7 M X L K J H 3 W G 6 2 V F T 1 U D E
5
ø A Max
N
VV Threads
1.81 Max (46.0 Max) Type 4 (metal)
© 2008 Glenair, Inc. www.glenair.com
CAGE CODE 06324
Printed in U.S.A. E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
D-32
233-101-G6 Type 4 Lanyard Release Plug for MIL-STD-1760
and Other MIL-DTL-38999 Series III Type Hybrid Signal, Power, Coax and Twinax Arrangements
TABLE I: CONNECTOR DIMENSIONS
SHELL SIZE 09 11 13 15 17 19 21 23 25 SHELL SIZE CODE A B C D E F G H J A MAX 1.00 (25.4) 1.110 (28.19) 1.972 (50.1) 2.078 (52.8) 2.204 (56.0) 2.330 (59.2) 2.472 (62.8) 2.594 (65.9) 2.704 (68.7) W THREAD M12 x1-6g-0.100R M15 x1-6g-0.100R M18x1-6g-0.100R M22x1-6g-0.100R M25x1-6g-0.100R M28x1-6g-0.100R M31x1-6g-0.100R M34x1-6g-0.100R M37x1-6g-0.100R Symbol M Z1 ZL NF
TABLE lI: FINISH
Finish Al alloy, Electroless Nickel CRES, Passivated CRES, Electrodeposited Nickel Al alloy, Olive Drab Cadmium over Nickel
TABLE III: LANYARD LENGTH CODE
CODE A B C D E F L ± .236 (±6) 4.016(102) 4.527(115) 5.000(127) 5.511(140) 6.024(153) 6.535(166) CODE G H I J K L L ± .236 (±6) 7.007(178) 7.519(191) 7.992(203) 8.503(216) 9.015(229) 9.527(242) CODE M N P R S T L ± .236 (±6) 10.000(254) 10.511(267) 11.023(280) 11.535(293) 12.007(305) 12.519(318) CODE U V W X Y Z L ± .236 (±6) 13.031(331) 14.015(356) 15.000(381) 16.023(407) 17.007(432) 18.031(458)
TABLE IV: SUPPLIED COMPONENTS
Contact Size 22D 20 16 12 12 8 8 Contact Pin Part Number M39029/58-360 M39029/58-363 M39029/58-364 M39029/58-365 M39029/102-558 Coax M39029/60-367 Coax M39029/90-529 Twinax Contat Socket Part Number M39029/56-348 M39029/56-351 M39029/56-352 M39029/56-353 M39029/103-559 Coax M39029/59-366 Coax M39029/91-530 Twinax Sealing Plug Part Number M27488-22 M27488-20 M27488-16 M27488-12 M27488-12 M27488-8 M27488-8 Insertion/Removal Tool Part Number M81969/14-01 M81969/14-10 M81969/14-03 M81969/14-04 M81969/14-04 M81969/14-06 M81969/14-06
APPLICATION NOTES
1. 2. Assembly to be identified with Glenair’s name and part number. 3. 4. This connector mates with D38999/20 and /24, Dimensions in parenthesis are metric and for reference. Blue color band indicates rear release retention system. Connectors to be supplied with contacts, insertion/removal tools and sealing plugs. Quantity of contacts includes spares (see Table IV). Material/finishes: 5. Shell, coupling sleeve, lanyard ring—Aluminum alloy or CRES 6. per Table I Retaining clips—Beryllium copper/gold plated Insulators––High grade rigid dielectric/NA Wave spring, retaining rings––Cres Grounding Spring––Beryllium copper/electroless nickel Seals––fluorosilicone/NA
© 2008 Glenair, Inc. www.glenair.com
CAGE CODE 06324
Printed in U.S.A. E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
D-33
